RBC 20 Advanced Lithium Battery Charger

LED Diagnostic

Charger

Icon

Solid Light

Blinking Light

Meaning

— Yellow

Charger is plugged in with no battery installed -

ready to charge.

Yellow (2 sec.) — Battery condition being checked by charger.

— Green (Slow) Battery is being charged. Charge level <85%.

— Green (Fast) Battery is being charged. Charge level >85%.

Green — Battery fully charged.

— Red

Battery is misaligned in charger. Remove bat-

tery and reinsert onto charger.

Battery is damaged. See Accessories Section to

select an appropriate replacement battery. See

Recycling Section for disposal instructions.

Charger is damaged. See Service and Repair

section for contact information.

Red —

Battery or charger outside of charging range

(41°F (5°C) to 104°F (40°C)). Allow battery and

charger to reach temperature range by sitting

in a conditioned environment.

NO LEDs ON

Charger does not have power. Ensure that

charger is properly connected to electrical

outlet.

Charger is not working properly. See Service

and Repair Section for contact information.
