ENGLISH en
15
7.11 Chuck with quick-change system Quick
Fig. I
To remove: Push the interlock ring forward (a),
advance and pull off the chuck (b).
To fit: push the interlock ring forward and move the
chuck as far as the limit stop on the drill spindle.
7.12 Fitting the belt hook (equipment-
specific) / bit depot (equipment-specific)
Fig. J
Fit the belt hook (8) as shown.
Fit the bit depot (7) as shown.
8.1 Defective electronic safety shutdown
(...LTX BL...)
Red continuous lighting
of the LED lamp (14)
signals a defective safety shutdown.Have the
machine repaired. See chapter 10.
8.2 The machine's multifunctional
monitoring system
If the machine switches off automatically, the
machine electronics have activated automatic
protection mode. There will be a warning signal
(beep). The beeping stops after a maximum of 30
seconds or when the trigger switch (15) is released.
In spite of this protective function, overloading
is still possible with certain applications and
can result in damage to the machine.
Causes and remedies:
1. Battery pack almost empty Fig. A, B (The
electronics protect the battery pack against
damage through total discharge).
If one LED (11) is flashing, the battery pack is
almost flat. If necessary, press the button (10)
and check the LEDs (11) to see the charge level.
If the battery pack is almost flat, it must be
recharged.
2. Long continuous overloading of the machine will
activate the temperature cut-out.
Leave the machine or battery pack to cool.
Note:
if the battery pack feels very warm, the
pack will cool more quickly in an "AIR COOLED"
charger.
Note:
the machine will cool more quickly if you
operate it at idling speed.
3. Metabo safety shutdown: the machine has
SHUT DOWN by itself. If the speed suddenly
drops (for example, if the machine suddenly
seizes or kickback occurs), the machine
switches off. Switch off the machine at the
trigger switch (15). Switch it on again and
continue to work as normal. Try to prevent the
machine from seizing.
8.3 Note:
The LED lamp (14) switches off automatically after
a specific time.
Use only original Metabo or CAS (Cordless Alliance
System) battery packs and accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating
instructions.
Fit accessories securely. If the machine is operated
in a holder: secure the machine well. Loss of control
can cause personal injury.
For a complete range of accessories, see
www.metabo.com or the catalogue.
Repairs to electrical tools must ONLY be
carried out by qualified electricians!
Contact your local Metabo representative if you
have Metabo power tools requiring repairs. See
www.metabo.com for addresses.
You can download a list of spare parts from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Battery packs may not be disposed of with regular
waste. Return faulty or used battery packs to your
Metabo dealer!
Do not allow battery packs to come into contact with
water!
Protect the environment, and do not dispose
of power tools and battery packs with house-
hold waste. Observe national regulations on
separated collection and recycling of disused
machines, packaging and accessories.
Discharge the battery pack in the power tool before
disposal. Prevent the contacts from short-circuiting
(e.g. by protecting them with adhesive tape).
Fig. K. We reserve the right to make technical
improvements.
U = Voltage of battery pack
n
0
= No-load speed
Tightening torque for screwing:
M
1
= Soft screwing application (wood)
M
2
=Pulse torque
M
3
= Hard screwing applications (metal)
M
4
= Adjustable torque
D
1 max
= Max. thread diameter
D
2 max
= Max. drill bit diameter in steel
D
3 max
= Max. drill bit diameter in soft wood
m = Weight (with the smallest battery pack)
G=Spindle thread
D
max
= Chuck clamping range
8. Troubleshooting
9. Accessories
10. Repairs
11. Environmental Protection
12. Technical Data
