5. POWER SUPPLY

Before starting the motor, make certain the power

socket incorporates a residual current device with a

tripping current not greater than 30 mA.

The hedge trimmer is designed for use only with

single-phase alternating current from a 230 V~ – 50

Hz AC supply. It is totally insulated, enabling it to be

connected also to socket-outlets without a PE con-

ductor. Before you use the hedge trimmer for the

rst time, check that your mains voltage is the same

as the operating voltage specied on the machine’s

rating plate.

6. START UP AND OPERATION

Assembly of the protection shield (Fig. 3)

Slide the included protection shield (2, Fig. 1)

over the blade rail and x it from both sides at the

housing using 1 screw on each side as shown in

Fig. 3.

CAUTION! - is hedge trimmer is designed to cut

hed ges, bushes and shrubs. Any other use which is

not expressly permitted in these instructions may

cause damage to the hedge trimmer and place the

user at serious risk. Your hedge trimmer is equipped

with a two-hand safety circuit (Fig. 4). is means

that it works only when the switch button on the

guide handle (B) is pressed with the one hand while

the switch on the handle (A) is being pres sed with

the other hand. If you let go of either swit ching

element, the blades will stop moving.

e blades take time to slow down to a standstill.

Please make allowance.

- Since the machine is equipped with an electric

brake which locks the blade, a harmless flash of

light may be seen in the top part of the machine

when the switch is released.

- Check that the blades are working properly. High

cutting performance and smooth operation are

guaranteed by the counter-rotating, dual-edge

blades.

- Fasten the extension cable in the corresponding

cable holder (see Fig.5) each time before you use

the hedge trimmer.

- Use only approved extension cables for outdoor

use.

EXTENSION CABLE RECOMMENDED LENGHT

(230 V)

Lenght Minimum conductor section

0 ÷ 20 meters 1 mm

20 ÷ 50 meters 1,5 mm

50 ÷ 100 meters 4 mm

7. PRACTICAL TIPS

• HANDLE (Fig.6) - To reduce fatigue when

trimming hedges, the handle can be swivelled

through 45° or 90° to the left or right.

Proceed as follows: free the handle by pressing

the locking lever (C). Please bear in mind that the

locking pin (C) can only be pulled back when the

switch (A) is not activated (held down). Make sure

that the locking pin locks into place again after

repositioning the turning handle. Only then the

switch can be activated anew.

• The hedge trimmer can be used to cut shrubs and

bushes as well as hedges.

• For the best performance, hold the hedge trim mer

with its teeth at an angle of approx. 15° to the

hedge (see Fig.7).

• Cutting in both directions is possible with the

dual-edge blades.

• To trim your hedge to a uniform height, run a

length of string along the hedge for guidance and

cut off the projecting branches.

• Cut the sides of the hedge with sweeping

move ments from the bottom up (see Fig.8).

4. TECHNICAL DATA

Oleo-Mac HC 605 E Efco TG 605 E

Voltage V~ 230

Frequency Hz 50

Current imput A 2.6

Power W 600

Cutting length mm 550

Blade pitch mm 30

Cutting thickness max. mm 15

Revolution min

-1

3400

Weight kg 3.6

Pressure level L

av EN 60745-1 – EN 60745-2-15

dB (A) 78.0 (Uncertainty 3.0)

Measured sound power level

2000/14/EC – EN 60745-1 – EN 60745-2-15 – EN ISO 3744

dB (A) 95.4 (Uncertainty 2.6)

Guaranteed sound power level

2000/14/EC - EN 60745-1 – EN 60745-2-15 – EN ISO 3744

dB (A) 98.0

Vibration level EN 60745-1 – EN 60745-2-15 m/s

2.3 (sx) - 2.9 (dx) (Uncertainty 1.5)
