12 Instructions for use and maintenance

•

conductor with blue insulation- to the neutral

conductor of the wiring (N)

•

conductor with yellow-green insulation – to the safety

conductor of the wiring ( )

3.2. Models without power cord

The appliance has to be connected to a separate electricity

circuit of the stationary electrical wiring. The circuit has

to be supplied with a safety fuse 16A (20A for power

> 3700W). Copper single core (rigid – non stranded)

conductor shall be used for the connection – cable 3 x 2.5

mm² (cable 3 x 2.5 mm² for power > 3700W).

The electrical circuit supplying the appliance must have an

in-built device ensuring the splitting of all terminal poles

under conditions of super-voltage of category III.

To install the power supply wire to the boiler, remove the

plastic cover (Fig.2).

Connect the power wires in compliance with the marks on

the terminals, as follows:

•

the phase - to mark A, A1, L or L1;

•

the neutral - to N (B or B1 or N1)

•

The safety wire must be obligatory connected to the

screw joint marked with .

After the installation, put the plastic cover back in its place!

Explanations to Fig. 3:

T2 - thermal switch; T1 - thermal regulator; S - switch;

R - heater; SL1, SL2, SL3 - light indicator; F - ﬂange; АТ -

anode tester (only for models that have one); AP - anode

protector;

VI. RUST PROTECTION MAGNESIUM ANODE (FOR

WATER HEATERS WITH WATER TANKS COVERED BY

GLASS-CERAMICS COATING)

The magnesium anode protects the water tank’s inner

surface from corrosion. The anode’s term of use is up to

ﬁve years. The anode element is an element undergoing

wear and tear and is subject to periodic replacement.

In view of the long-term and accident free use of your

water heater, the manufacturer recommends periodic

inspections of the magnesium anode’s condition by a

qualiﬁed technician and replacement whenever required,

and this could be performed during the appliance’s

technical preventive maintenance. For replacements,

please contact the authorized service stations!

VII. OPERATION

1. Switch on

Before switching on the appliance for ﬁrst time, make sure

that the boiler is properly connected to the power supply

network and full with water. The boiler is switched on by a

switch integrated into the installation, described in item 3.2

of Section V, or upon connecting the plug to the electrical

contact (in the case of an extension cable with plug).

2. Water heaters with electromechanical control

Fig. 2 shows:

1 - Thermal regulator

2 - Power switch

3 - Indicator lights

4 - Anode tester

Thermal regulator (1) and indicator light for „heating

up / ready to use“

Setting of the temperature is provided by a knob for

the thermal regulator (1). This setting allows for gradual

adjustment to the desired temperature.

Fig.2 displays the rotation direction of the knobs.

e ENERGY SAVING – in this mode the water in the

appliance is at a temperature of approximately 60°С. Thus

thermal loss is reduced.

Indicator light “heating up / ready to use“ - indicates

the status/operation mode of the appliance: the light is

red while the water is heated and it is blue when the water

has reached the temperature as set by the thermostat. The

light is oﬀ when the power switch is in oﬀ position.

Power switch (2) and indicator lights

Single-level power switch:

0 – power is oﬀ;

I – power is on;

The power indicator light for I is on when the switch is

turned on at level I.

Power switch with two levels:

0 – power is oﬀ;

I, II – power is on;

Selection of levels of heating power:

Rated power

(as marked on the nameplate

of the appliance )

Switched to

level (I)

Switched to

level (II)

1200 W 600 W 1200 W

1600 W 800 W 1600 W

2400 W 1200 W 2400 W

At level I of the switch, the power indicator light I is on.

At level II of the switch both power indicator lights I and

II are on.

Anode tester (4)- (with models, having an integrated

tester).

This facility serves for the identiﬁcation of the current

state of magnesium anode and indicates the need for its

replacement. The anode tester is secured with button 4 and

light indication 5 next to it (Fig.2). The state of the anode

protector can be controlled by pressing button 4 ( )
