The stapler is equipped with a movable trigger to prevent

accidental starting. Pressing the trigger on the material

and pressing the trigger button will release the staple / nail.

LIGHTING

Each time the light switch button ( 4 ) is pressed, two LEDs ( 8 )

located on both sides of the stapler illuminate the workplace.

The LEDs ( 8 ) also light up after pressing the trigger ( 3 )

regardless of the lighting switch ( 4 ) (Fig. F) .

STAPLING NAILS OR NAILS

The stapler is adapted to work in two modes: single hammering

and contact hammering.

Single hammer mode is designed for precise hammering.

Single hammer mode:

• Set the mode switch ( 5 ) to the left (Single firing position ) for

single stapling / nails ( fig. G ) .

• Rest and press the trigger ( 1 ) against the workpiece to form

a 90 ° angle.

• Press the trigger ( 3 ) to fire the staple or nail ( fig. H ) .

• Release the trigger ( 3 ) and trigger ( 1 ).

Contact stick mode:

• Set the mode switch ( 5 ) to the right

( Contact firing position ) to drive in staples / nails ( fig. G ) .

• Press and hold the trigger ( 3 ).

• Press the trigger ( 1 ) against the workpiece to shoot a nail or

staple ( fig. I ) .

• Keeping the trigger ( 3 ) pressed, release the pressure on the

trigger, move the stapler to another position and press the

trigger ( 1 ) again to drive another nail or staple. The operation

can be repeated many times without having to press the

trigger each time. Remember to release the pressure on the

trigger each time the staple is driven in ( 1 ).

ADJUSTING THE DEPTH OF STAPLES / NAILS

The depth adjustment knob ( 2 ) helps to protect the work

surface and allows the correct setting of the staple / nail driving

depth ( fig. J ) .

- turning the depth adjustment knob ( 2 ) towards the mark

increases the staple / nail driving depth.

- by turning the depth adjustment knob ( 2 ) towards the

mark , the staple / nail driving depth is reduced.

WARNING CONTROL

A warning indicator (LED) ( 6 ) indicates irregularities in the

work of the stapler ( fig. K ) :

• LED pulsates red - staple or nail jammed

• LED is steady red - battery is low.

• LED pulsates green - device overheating.

• LED is steady green - no staples / nails in the magazine.

REMOVING A CLAMMED NAIL OR STAPLES

Warning! Remove the jammed nail / staple before using the

device. Otherwise, it may damage the stapler mechanism.

• Remove the battery from the device.

• Open the magazine and remove all staples / nails ( fig. L ).

• Loosen the screws of the flail cover ( 13 ) (without removing

it) with the supplied hex key ( fig. M ).

• Remove the jammed nail / staple and tighten the loose

screws of the flail cover ( 13 ) ( fig. N ).

HANDLE

The stapler has a practical handle ( 12 ) which is used for

hanging on the assembly belt when working at height.

MAINTENANCE AND MAINTENANCE

WARNING! Remove the battery from the device before

performing any installation, adjustment, repair or

maintenance operations.

MAINTENANCE AND STORAGE

• After each use, wipe the outer casing with a cloth.

• Do not use any cleaning agents or solvents as they may

damage the plastic parts .

• Make sure that no water gets into the device.

• Only the maintenance procedures described in this manual

may be carried out at the device. All other activities may only

be carried out by an authorized service center.

• Do not make any changes to the design of the device.

• When not in use, the stapler should be stored clean, in a dry

place, out of reach of children.

• The device should be stored with the battery removed.

All defects should be removed by the manufacturer's authorized

service department.

TECHNICAL SPECIFICATIONS

RATED DATA

Stapler 58G081

Parameter

Value

Battery voltage

18V DC

Maximum number of operations per

minute

100

Average number of operations per

minute

Maximum nail length

50 mm

Maximum staple length

40 mm

Maximum magazine capacity (staples /

nails)

100

Protection class

III

Weight (without batteries)

2.7 kg

Year of production

58G081 means both machine type and machine definition

NOISE AND VIBRATION DATA

Sound pressure level

= 79.9 dB (A) K = 3dB

(A)

Sound power level

= 90.9 dB (A) K =

3dB (A)

Acceleration value

= 1.39 m / s

K = 1.5

m / s

Information on noise and vibration

The level of noise emitted by the device is described by: the

sound pressure level Lp

and the sound power

level Lw

(where K is the measurement uncertainty). Vibration

emitted by the device is described by the value of vibration

acceleration a

(where K is the measurement uncertainty).

The level of emitted sound pressure Lp

, the sound power

level Lw

and the value of vibration acceleration a

given in this

manual were measured in accordance with EN 60745-1:

2012. The specified vibration level a

can be used to compare

devices and to initially assess vibration exposure.

The given vibration level is representative only for the basic

applications of the device. If the device is used for other

applications or with other working tools, the vibration level may

change. Higher vibration levels will be affected by insufficient or

too rare maintenance of the device. The above-mentioned

causes may cause increased vibration exposure during the

entire working period.

To accurately estimate vibration exposure, consider the

periods when the device is turned off or when it is turned

on but is not used. After careful estimation of all factors,

the total vibration exposure may be much lower.

To protect the user against the effects of vibrations, additional

safety measures should be introduced, such as: cyclic
