16

Код

Номер

Название детали

Кол-во

1030116914

JDC1001

Left panel cover

1

1030116915

JDC1002

Right panel cover

1

1030116916

JDC1003

Battery box cover assembly

1

2010016558

JDC1013

Tensioning wheel

1

2010016982

JDC1014

Tensioned toothed plate

1

2010016983

JDC1024

Welded toothed plate

1

2010016984

JDC1028

Sliding toothed block

1

1030116917

JDC1033

Left shell

1

1030116918

JDC1034

Right shell

1

2010013125

JD1009

Base

1

1031011105

JDC1010

Welding button

1

2010013126

JD1012

Left side panel

1

2010013503

JD1013

Tensioning wheel

1

2010013573

JD1015

Connecting shaft

1

1030113397

JD1016

Connecting shaft spring

1

1030113524

JD1017

Welding stand spring

1

2010013129

JD1018

Welding stand

1

2010013143

JD1018-1

Stand roller shaft pin

1

2010013144

JD1018-2

Stand roller shaft

1

2010013145

JD1019

Locating pin of welding stand

1

2010013146

JD1020

Welding fulcrum shaft

1

2010013128

JD1021

Welding lock block

1

2010013574

JD1022

Spring fixed collar

1

2010013130

JD1024

Welded toothed plate

1

2010013147

JD1025

Setscrews pin of welding lower toothed plate

1

2010013131

JD1027

Sliding chute framework

1

2010013132

JD1028

Sliding toothed block

1

2010013133

JD1029

Cutter

1

1030113525

JD1030

Cutter spring 13

1

1030113526

JD1030-1

Cutter spring 16

1

2010013669

JD1031

Cutterfixed screw assembly

1

2010013148

JD1031-2

Cutter bush

1

1030113527

JD1032

Tension spring of sliding chute framework

1

2010013537

JD1033

Left shell

1

2010013538

JD1034

Right shell

1

1020200900

JD1036

Welding motor

1

2010013539

JD1040

Eccentric shaft

1

2010013540

JD1041

Eccentric shaft belt pulley

1

2010013541

JD1042

Motor belt pulley

1

1021503506

JD1043

Transmission belt

1

2010020283

JDC1044

Synchronous belt

1

2010013149

JD1044-1

Handle

1

2010013150

JD1044-2

Handle steady pin I

1

2010013151

JD1044-3

Handle steady pin II

1

2010013152

JD1044-4

Handle touching pin

1
