English

• Align the cutting edge of blade 23 along the lug of

blade alignment xture 14� Press the vertical part of

adjusting plate 21 to the vertical surface of blade align-

ment xture 14 as shown in gure 8.2. Match the holes

in adjusting plate 21 with the holes in blade 23 mov-

ing adjusting plate 21 along blade alignment xture 14�

Tighten screws 22� If the length of blade 23 is not

sufcient for alignment due to multiple resharpen-

ing both blades 23 must be replaced.

• Place blade 23 assembled with adjusting plate 21 on

drum 24 as shown in gure 8.3.

• Place cover 20 and tighten bolts 19 using box

wrench 15 (see g. 9).

• Repeat the above operations for the second

blade 23�

Sharpening of the resharpenable blades (see g. 8)

Always sharpen both blades 23 at the

same time and only using blade sharpen-

ing device 13, as this will ensure the right

sharpening angle.

• Dismantle both blades 23 as described above�

• Loosen winged nuts 29 and place both blades 23

into blade sharpening device 13 (see g. 8.1). The

back parts of blades 23 must rest on stops of tem-

plate 26�

• Tighten winged nuts 29� Heads of clamping bolts 25

and plate 27 shall securely x both blades 23 pressing

them against template 26 to prevent their movement�

Cutting edges of blades 23 shall be located in same

plane (see g. 8.1).

• Sharpen both blades 23 at the wet hard-grained

grinding stone�

• Finish both blades 23 at the wet ne-grained nish-

ing grinding stone� It is also recommended to polish

cutting edge surfaces of blades 23 as this will ensure

best operational results�

• Install both blades 23 as described above�

Replacement of driving belt (see g. 10)

• Unscrew housing screws 31 of protective casing 8

and remove it (see g. 10).

• Remove the worn driving belt 30�

• Clean the belt pulleys with a brush�

• Place a new driving belt 30 onto the driving pulley

(smaller diameter) and than pull in on the driven pulley

(larger diameter) rotating drum�

• Place protective casing 8 back and tighten

screws 31�

Cleaning of the power tool

An indispensable condition for a safe long-term exploi-

tation of the power tool is to keep it clean� Regularly

ush the power tool with compressed air thought the

ventilation slots 10�

After-sales service and application service

Our after-sales service responds to your questions

concerning maintenance and repair of your product as

well as spare parts� Information about service centers,

parts diagrams and information about spare parts can

also be found under: www.dwt-pt.com�

•

Transportation

of the power tools

Categorically not to drop any mechanical impact on

the packaging during transport�

• When unloading / loading is not allowed to use any

kind of technology that works on the principle of clamp-

ing packaging�

Environmental

protection

Recycle raw materials instead of dispos-

ing as waste.

Power tool, accessories and packaging

should be sorted for environment-friendly

recycling�

The plastic components are labelled for categorized

recycling�

These instructions are printed on recycled paper man-

ufactured without chlorine�

The manufacturer reserves the possibility to introduce changes.
