OCV Multifunctional Truck
For all those aiming high
Features
1.1 Manufacturer STILL
1.2 Manufacturer’s type designation OCV 01
1.3 Drive Electric
1.4 Operation Stand-on
1.5 Rated capacity of the lifting platform Q1 kg 90
Rated capacity of the front platform Q2 kg 110
Rated capacity of the stand-on platform Q3 kg 136
1.9 Wheel base y mm 1095
Weights
2.1 Service weight (incl. battery) kg 800
2.2 Axle load, laden front/rear kg 590/410
2.3 Axle load, unladen front/rear kg 380/420
Wheels
3.1 Tyres Polyurethane/rubber
3.2 Tyre size front mm ⌀ 210 x 70
3.3 Tyre size rear mm ⌀ 250 x 100
3.4 Additional wheel size mm ⌀ 74 x 48
3.5 Number of wheels (x = driven) 1x+2/2
3.6 Track width front b
10
mm 545
3.7 Track width rear b
11
mm 640
Basic dimensions
4.2 Height of mast when lowered h
1
mm 1375
4.4 Lift h
3
mm 3620
4.5 Height of mast when raised h
4
mm 4100
4.7 Height above overhead guard (cab) h
6
mm 1425
4.8 Seat height/standing height h
7
mm 285
4.14 Platform height, raised h
12
mm 3000
4.19 Overall length l
1
mm 1440
4.21 Overall width b
1
/b
2
mm 750
4.32 Ground clearance m
2
mm 35
4.34 Working aisle width A
st
mm 1850
4.35 Turning radius W
a
mm 1260
Performance data
5.1 Driving speed (h [standing height h
12
] = 0-500 mm) laden/unladen km/h 6.0/6.5
Driving speed (h = 500–1000 mm) laden/unladen km/h 3
Driving speed (h = 1000–2000 mm) laden/unladen km/h 2
Driving speed (h = 2000–3000 mm) laden/unladen km/h 1
5.2 Lifting speed Q3 (stand-on platform) laden/unladen m/s 0.22/0.27
Lifting speed Q1 (lifting platform) laden/unladen m/s 0.038/0.040
5.3 Lowering speed Q3 laden/unladen m/s 0.31/0.25
Lowering speed Q1 laden/unladen m/s 0.040/0.038
5.8 Max. gradeability laden/unladen % 1.8/1.8
5.10 Service brake Electromagnetic
Electric engine
6.1 Drive motor, rating S2 = 60 min kW 0.65
6.2 Lift motor, rating S3 = 15 % kW 2.2
6.4 Battery voltage/rated capacity K
5
V/Ah 24/135
6.5 Battery weight kg 50
6.6 Energy consumption according to VDI cycle kWh/h 0.387
Misc.
8.1 Transmission control DC control
8.4 Sound pressure level (operator's position) dB(A) 74
This specification sheet, which conforms to VDI Guideline 2198, provides the technical values for the
standard equipment only. Different tyres and the use of accessories etc. may result in other values.
