22

ITEM NO. PART NO. DESCRIPTION QTY

1 3410298A-10 Left upper handle 1

2 3410801 Wire clip 1

3 3220298 Screw 2

4 3111098-10 Auxiliary handle assembly 1

5 3412698-10 Knob 1

6 3220698 Bolt 1

7 3410598-10 Knob 1

8 3220398 Screw 2

9 3412398-10 Carry bar 1

10 3410898-10 Front housing 1

11 3390198 Spring 1

12 3111198 Tension wheel assembly 1

13 3390298 Spring 2

14 3220298 Screw 10

15 3330298 Left cover 1

16 3220998 Cover nut 1

17 3290499 Washer 1

18 3220236 Nut 1

19 3290499 Washer 1

20 3330198 Impeller pulley bracket 1

21 3220298 Screw 3

22 3290198 Belt 1

23 32262198 Washer 2×13 1

24 3220598 Screw 3

25 3111298A Impeller pulley assembly 1

26 3320198 Impellor shaft 1

27 3111398A-10 Impellor assembly 1

28 3412098A Snow spade 1

29 3291499 Washer 3

30 3220905 Screw 3

31 32261198 Washer 1

32 3220298 Screw 8

33 3411798 Right cover 1

34 3220298 Screw 6

35 3111498 Motor assembly 1

35-1 3610498 Carbon brush assembly 2

36 3330398 Motor mounting bar 1

37 3220475 Screw 2

38 3410998-10 Rear housing 1

39 3220298 Screw 8

40 3111598-10 Right grill assembly 1

41 3412798 Protect pacer 1

PARTS LIST
