Page 8 / 64 MXH Rev22_ - Operating Instructions

THIS INSTRUCTION MANUAL IS THE PROPERTY

OF CALPEDA S.P.A. ANY REPRODUCTION, EVEN

IF PARTIAL, IS FORBIDDEN

1. GENERAL INFORMATION

Before using the product carefully read the information

contained in this instruction manual, the manual should

be kept for future reference.

Italian is the original language of this instruction

manual, this language is the reference language in

case of discrepancies in the translations.

This manual is part of the essential safety requirement

and must be retained until the product is nally de-

commissioned.

The customer, in case of loss, can request a copy

of the manual by contacting Calpeda S.p.A. or their

agent, specifying the type of product data shown on

the label of the machine (see 2.3 Marking)

Any changes, alterations or modications made to the

product or part of it, not authorized by the manufacturer,

will revoke the “CE declaration” and warranty.

This appliance should not be operated

by children younger than 8 years,

people with reduced physical, sensory

or mental capacities, or inexperienced

people who are not familiar with the

product, unless they are given close

supervision or instructions on how to

use it safely and are made aware by

a responsible person of the dangers

its use might entail. Children must not

play with the appliance.

It is the user's responsibility to clean

and maintain the appliance. Children

should never clean or maintain it

unless they are given supervision.

Do not use in ponds, tanks or swimming

pools or where people may enter or

come into contact with the water.

Read carefully the installation

section which sets forth:

The maximum permissible structural

working pressure (chapter 3.1).

- The type and section of the

power cable (chapter 6.5).

- The type of electrical protection

to be installed (chapter 6.5).

1.1. Symbols

To improve the understanding of the manual, below are

indicated the symbols used with the related meaning.

Information and warnings that must be

observed, otherwise there is a risk that the

machine could damage or compromise

personnel safety.

The failure to observe electrical information

and warnings, could damage the machine or

compromise personnel safety.

Notes and warnings for the correct management

of the machine and its parts.

Operations that could be performed by the nal

user. After carefully reading of the instructions,

is responsible for maintenance under normal

conditions. They are authorized to affect

standard maintenance operations.

Operations that must be performed by a

qualied electrician. Specialized technician

authorised to affect all electrical operations

including maintenance. They are able to

operate with in the presence of high voltages.

Operations that must be done performed by

a qualied technician. Specialized technician

able to install the device, under normal

conditions, working during “maintenance”,

and allowed to do electrical and mechanical

interventions for maintenance. They must

be capable of executing simple electrical

and mechanical operations related to the

maintenance of the device.

Indicates that it is mandatory to use individual

protection devices.

OFF

Operations that must be done with the device

switched off and disconnected from the power

supply.

Operations that must be done with the device

switched on.

1.2. Manufacturer name and address

Manufacturer name: Calpeda S.p.A.

Address: Via Roggia di Mezzo, 39

36050 Montorso Vicentino - Vicenza / Italia

www.calpeda.it

1.3. Authorized operators

The product is intended for use by expert operators

divided into end users and specialized technicians.

(see the symbols above).

It’s forbidden, for the end user, carry out

operations which must be done only by

specialized technicians. The manufacturer

declines any liability for damage related to the

non-compliance of this warning.

1.4. Warranty

For the product warranty refer to the general terms and

conditions of sale.

SUMMARY

1. GENERAL INFORMATION ............................. 8

2. TECHNICAL DESCRIPTION ..........................9

3. TECHNICAL FEATURES ................................9

4. SAFETY .......................................................... 9

5. TRANSPORTATION AND HANDLING .........10

6. INSTALLATION .............................................10

7. STARTUP AND OPERATION ....................... 11

8. MAINTENANCE ............................................ 11

9. DISPOSAL ....................................................12

10. SPARE PARTS .............................................12

11. ESIGNATION OF PARTS ............................. 12

12. TROUBLESHOOTING .................................. 13

Installation examples ....................................61

Drawing for dismantling and assembly .................. 62

Declaration of conformity ....................................... 64

MXH Rev22_.indd 8 31/05/18 08:43
