PRODUCT SPECIFICATIONS

Motor 18 V DC

No Load Speed 3000 min

-1

Battery Pack 18 V

Charging Rate 1 to 1-1/2 hour

Cutting Capacity 102 mm

Weight With Battery Pack 3.5 kg

Battery pack (not included) BPP-1817M /

BPP-1815M /ABP1801 /

ABP1802 /

BPP-1817MG / BPL-

1820 / BPL-1820G

Charger (not included) BC-1800 / BC-1800M /

BC-1815S / BC-

1815SMG /

ACR1800 / BCL-1800 /

BCL-1800G

*BATTERIES AND CHARGERS SOLD SEPARATELY

FEATURE

Fig. 2

A. 60o MAXIMUM

Fig. 3

A. TRIGGER LOCK BUTTON

B. REAR HANDLE

C. TRIGGER

D. BATTERY PACK (NOT INCLUDED)

E. ANCHOR SCREW

F. FRONT HANDLE

G. SHAFT ADJUSTMENT COLLAR

H MOTOR HOUSING

I. BLADE CLAMP LEVER

J. BLADE

Fig. 4

A. FRONT HANDLE

B. WING KNOB

C. BOLT

D. SPRING WASHER

E. FLAT WASHER

Fig 5 & 6

A. MOUNTING CLAMP

B. POSITIONING PIN HOLE

C. BLADE CLAMP LEVER

Fig. 7

A. BATTERY PACK (NOT INCLUDED)

B. LATCHES

Fig. 8

A. SHAFT ADJUSTMENT COLLAR

B. LOWER PORTION OF SHAFT ADJUSTMENT

COLLAR

C. TO UNLOCK COLLAR

Fig. 9

A. SLIDE OUT TO DESIRED POSITION

Fig. 10

A. SHAFT ADJUSTMENT COLLAR

B. LOWER PORTION OF SHAFT ADJUSTMENT

COLLAR

C. TO LOCK COLLAR

Fig. 11

A. TRIGGER LOCK BUTTON

B. TRIGGER

Fig. 12

A. SECOND CUT

B. LOAD

C. FIRST CUT 1/4 DIAMETER

D. FINAL CUT

Fig. 13

A. CUTTING GUIDE

ASSEMBLY

KNOW YOUR POLE PRUNER

See Figure 3.

■ Before attempting to use the pole pruner, familiarize

yourself with all operating features and safety

requirements.

WARNING

If any parts are missing, do not operate your pole

pruner until the missing parts are replaced.

Failure to do so could result in possible serious

personal injury.

ATTACHING THE FRONT HANDLE

■ Press the front handle onto the shaft. See Figure 4.

■ Move it to a position on the shaft suitable for the user.

■ Secure it with the bolt, wing knob and washers in the

sequence as shown.

■ Tighten the bolt to ensure the handle is fixed firmly.

INSTALLING AND REMOVING THE BLADE

WARNING

Failure to remove the battery pack from the pole

pruner could result in accidental starting which

could possibly cause serious personal injury.

INSTALLING THE BLADE

■ Remove the battery pack from the pole pruner

English

F D E I P NL S DK N FIN GR HU CZ RU RO PL SLO HR TR EST LT LV SK BG

OPS-1801_25 lgs manual 12/13/03 9:11 AM Page 10
