This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.

Translated from Italian

F INSTALLATION

FOREWORD K900 has a 3 inch inlet and outlet. It was designed for permanent installa-

tion on a distribution line and to this purpose, the measurement chamber is

fitted with a threaded inlet and outlet.

The two cables (each one consisting of two wires) sticking out from the

cover of the measurement chamber are to be connected to K900 remote

display.

WARNING

The position of the ﬁlter determines the input direction of the ﬂow.

The pulser must be connected by two wires observing the electrical

speciﬁcations shown in the diagram

Make sure a ﬁlter with adequate ﬁltering capacity is always ﬁed either

at meter inlet or at the entrance of the line on which the meter is ﬁt-

ted. If solid particles enter the measurement chamber, the gears could

seize.

On installations, place the meter in a position that will enable an easy

access to the baeries compartment
