INSTALLATION AND OPERATION GUIDELINES FOR REVERSE OSMOSIS SYSTEMS

ECOSOFT ROBUST 1000, ROBUST 1500 / 1500 ЕС, ROBUST PRO / PRO EC, ROBUST 3000 / 3000 EC

ENG

Puried water. Tube from pure water outlet to the puried water faucet.

Pressure tank. Not connected and mued.

Drain. Tube from the drain outlet to the drain saddle.

Inlet. Water supply tube from the water main.

Puried water. Tube from the pure water outlet to the puried water faucet.

Pressure tank*. Tube from the tank outlet to the valve on the tank.

Drain. Tube from the drain outlet to the drain saddle.

Inlet. Water supply tube from the water main.

*Pressure tank — oponal equipment, not included in the delivery.

For simplicity of installaon, the input and output ports in all RObust systems are arranged in

the same order.

3. INSTALLATION DIAGRAMS

3.1. ECOSOFT ROBUST BASE MODEL

3.2. ECOSOFT ROBUST WITH PRESSURE TANK

Puried

water

Drain Tank Inlet

Puried

water

Drain Tank Inlet
