English | 15
u Always wait until the power tool has come to a com-
plete stop before placing it down. The application tool
can jam and cause you to lose control of the power tool.
u Hold the power tool firmly with both hands and make
sure you have a stable footing. The power tool can be
more securely guided with both hands.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended use
The power tool is intended for copy routing as well as routing
grooves, edges, profiles and elongated holes in wood,
plastic and light building materials while resting firmly on the
workpiece.
Can even be used to machine non-ferrous metals when used
at a low speed with the appropriate router bits.
Product features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Lock button for on/off switch
(2)
Right handle (insulated gripping surface)
(3)
Spindle lock button
(4)
Wing bolt for parallel guide rods (2x)
(5)
Chip protection
(6)
Base plate
(7)
Guide plate
(8)
Holder for parallel guide rods
(9)
Step buffer
(10)
Protective sleeve
(11)
Wing bolt for depth stop adjustment
(12)
Slide with index mark
(13)
Depth stop
(14)
Scale for setting routing depth
(15)
Left handle (insulated gripping surface)
(16)
Clamping lever for locking the routing depth
(17)
Unlocking lever for guide bushing
(18)
Router bit
A)
(19)
On/off switch
(20)
Speed preselection thumbwheel
(21)
Cap nut with collet
(22)
Open-ended spanner (19mm)
(23)
Extraction hose (dia. 35 mm)
A)
(24)
Dust extraction adapter
(25)
Knurled screw for dust extraction adapter (2x)
(26)
Guide rod for parallel guide (2x)
(27)
Parallel guide
(28)
Centring pin
A)
(29)
Wing bolt for centring pin
A)
(30)
Curve guide
A)
(31)
Router compass/guide rail adapter
A)
(32)
Handle for router compass
A)
(33)
Wing bolt for router compass coarse adjustment
(2x)
A)
(34)
Wing bolt for router compass fine adjustment (1x)
A)
(35)
Knob for router compass fine adjustment
A)
(36)
Centring screw
A)
(37)
Guide rail
A)
(38)
Spacer plate (part of the router compass set)
(39)
Guide bushing
A)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical data
Router GOF 130
Article number
3601FB70..
Rated power input W 1300
No-load speed min
−1
11000–28000
Speed preselection ●
Constant electronic control ●
Connection for dust extraction ●
Compatible collets mm
inches
6/8
¼
Router cage stroke mm 55
Weight according to
EPTA-Procedure01:2014
kg 3.5
Protection class
/II
The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.
Noise/Vibration Information
Noise emission values determined according to
EN62841-2-17.
Bosch Power Tools 1 609 92A 5MT | (27.07.2020)
