18 | English

Routing with an auxiliary guide (seefigureF)

For machining large workpieces, e.g. when routing grooves,

you can fasten a board or straight edge securely to the work-

piece as an auxiliary guide. The router can be guided along

the path of this auxiliary guide. Move the router on the

flattened side of the guide plate along the auxiliary guide.

Edge or profile routing

For edge and profile routing without a parallel guide, the

router bit must be fitted with a pilot pin or a ball bearing.

While it is switched on, guide the power tool towards the

workpiece from the side until the pilot pin or the ball bearing

of the router bit is touching the side of the workpiece edge

that you want to machine.

Guide the power tool along the workpiece edge. Pay atten-

tion that the router is positioned perpendicularly. Too much

pressure can damage the edge of the workpiece.

Routing with a parallel guide (see figuresG–H)

Slide the parallel guide(27) with the guide rods(26) into

the base plate(6) and tighten it with the wing bolts(4) ac-

cording to the required dimension.

While it is switched on, guide the power tool along the work-

piece edge with a uniform feed and while applying lateral

pressure to the parallel guide.

Routing curves (see figuresI–J)

Turn the parallel guide(27) so that the guide surface is vis-

ible on top.

Slide the parallel guide(27) with the guide rods(26) into

the base plate(6) and tighten it with the wing bolts(4) ac-

cording to the required dimension.

Fit the centring pin(28) with the wing bolt(29) through the

hole on the parallel guide(27).

Push the centring pin(28) into the marked centre point of

the curve and carry out the routing process with a uniform

feed.

Routing with the curve guide (see figuresK–L)

Slide the parallel guide(27) with the guide rods(26) into

the base plate(6) and tighten it with the wing bolts(4) ac-

cording to the required dimension.

Fit the curve guide with guide roller attached(30) through

the hole on the parallel guide(27).

Guide the power tool along the workpiece edge, applying

light pressure to the sides.

Routing with a router compass (seefigureM)

You can use the router compass/guide rail adapter(31) for

circular routing work. Fit the router compass as shown in the

figure.

Screw the centring screw(36) into the thread of the router

compass. Position the tip of the screw in the centre point of

the curve you want to rout; make sure the tip of the screw

reaches the surface of the workpiece.

Roughly set the required radius by moving the router com-

pass and tightening the wing bolts(33) and(34).

Then loosen the wing bolt(34) and use the knob(35) to

fine-adjust the length. One revolution corresponds to an ad-

justment range of 2.0 mm. Each of the graduation marks on

the knob(35) changes the adjustment range by 0.1 mm.

Switch the power tool on and move it over the workpiece us-

ing the right handle(2) and the handle for the router com-

pass(32).

Routing with a guide rail (see figureN)

You can use the guide rail(37) to rout in straight lines.

To level out the height difference, you must fit the spacer

plate(38).

Fit the router compass/guide rail adapter(31) as shown in

the figure.

Fasten the guide rail(37) to the workpiece using suitable

clamping devices, e.g. screw clamps. Put the power tool

with mounted guide rail adapter(31) on the guide rail.

Routing with the guide bushing (see figures O–P)

Using the guide bushing(39), you can transfer contours

from templates or patterns to the workpiece.

Select the guide bushing that is suitable for the thickness of

the template or pattern. Due to the protruding height of the

guide bushing, the template must have a minimum thickness

of 8mm.

Move the release lever(17) and push the guide bush-

ing(39) into the base plate(6) from below. The coding

cams must audibly click into the recesses of the guide bush-

ing.

u Select a router bit with a diameter that is smaller than

the interior diameter of the guide bushing.

To rout with the guide bushing(39), proceed as follows:

– Switch the power tool on and move it with the guide bush-

ing towards the template.

– Push the clamping lever for locking the routing

depth(16) down and slowly move the router down until it

reaches the set routing depth. Release the clamping lever

for locking the routing depth(16) again to lock this

depth. If necessary, push the clamping lever for locking

the routing depth(16) up to fully lock it.

– Move the power tool with the protruding guide bushing

along the template, applying pressure to the sides.

Maintenance and Service

Maintenance and Cleaning

u Pull the plug out of the socket before carrying out any

work on the power tool.

u To ensure safe and efficient operation, always keep

the power tool and the ventilation slots clean.

u In extreme conditions, always use a dust extractor if

possible. Clean ventilation slots frequently using a

brush and install a residual current device (RCD) up-

stream. When machining metals, conductive dust can

settle inside the power tool, which can affect its protect-

ive insulation.

In order to avoid safety hazards, if the power supply cord

needs to be replaced, this must be done by Bosch or by an

1 609 92A 5MT | (27.07.2020) Bosch Power Tools
