10
ENGLISH
• ALWAYS remove the battery before making adjustments
or changingbits.
• Keep hands clear of bits when motor is running to
prevent personalinjury.
• Never touch the bit immediately after use. It may be
extremelyhot.
• Provide clearance under workpiece for router bit when
through-cutting.
• Tighten collet nut securely to prevent the bit
fromslipping.
• Never tighten collet nut without abit.
• Do not use router bits with adiameter in excess of
30mm in thistool.
• Avoid climb-cutting (cutting in direction opposite than
shown in FigureO). Climb-cutting increases the chance
for loss of control resulting in possible injury. When
climb-cutting is required (backing around acorner), exercise
extreme caution to maintain control of router. Make smaller
cuts and remove minimal material with eachpass.
• Always use straight-cutters, rabbet-cutters, profile cutters,
slotter cutters or grooved knives with ashank diameter that
corresponds to the size of the collet in yourtool.
• Always use bits suitable for aspeed of min. 30000 min
-1
and
markedaccordingly.
• Do not hand-hold the router in an upside-down or
horizontal position. The motor can separate from the base if
not properly attached according to theinstructions.
• Before starting the motor clear the work area of all
foreignobjects.
• Do not use in aroutertable.
• Always keep the chip shield (if included) clean and
inplace.
• Do not press spindle lock button while the motor is
running. Doing so can damage the spindlelock.
• Always make sure the work surface is free from nails and
other foreign objects. Cutting into anail can cause the bit
and the tool tojump.
Residual Risks
In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot be avoided. These are:
• Impairment ofhearing.
• Risk of personal injury due to flyingparticles.
• Risk of burns due to accessories becoming hot
duringoperation.
• Risk of personal injury due to prolongeduse.
SAVE THESE INSTRUCTIONS
Chargers
DEWALT chargers require no adjustment and are designed to be
as easy as possible tooperate.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the battery pack voltage corresponds to the
voltage on the rating plate. Also make sure that the voltage of
your charger corresponds to that of yourmains.
Your DEWALT charger is double insulated in
accordance with EN60335; therefore no earth wire
isrequired.
If the supply cord is damaged, it must be replaced by
aspecially prepared cord available through the D
EWALT
serviceorganisation.
Mains Plug Replacement
(U.K. & Ireland Only)
If anew mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 3A.
Using an Extension Cable
An extension cord should not be used unless absolutely
necessary. Use an approved extension cable suitable for
the power input of your charger (see Technical Data). The
minimum conductor size is 1mm
2
; the maximum length
is30m.
When using acable reel, always unwind the cablecompletely.
Important Safety Instructions for All Battery
Chargers
SAVE THESE INSTRUCTIONS: This manual contains important
safety and operating instructions for compatible battery
chargers (refer to TechnicalData).
• Before using charger, read all instructions and cautionary
markings on charger, battery pack, and product using
batterypack.
WARNING: Shock hazard. Do not allow any liquid to get
inside charger. Electric shock mayresult.
WARNING: We recommend the use of aresidual current
device with aresidual current rating of 30mA orless.
CAUTION: Burn hazard. To reduce the risk of injury,
charge only D
EWALT rechargeable batteries. Other types of
batteries may burst causing personal injury anddamage.
CAUTION: Children should be supervised to ensure that
they do not play with theappliance.
NOTICE: Under certain conditions, with the charger
plugged into the power supply, the exposed charging
contacts inside the charger can be shorted by foreign
material. Foreign materials of aconductive nature such as,
but not limited to, steel wool, aluminum foil or any buildup
of metallic particles should be kept away from charger
cavities. Always unplug the charger from the power supply
