Bit Installation and Removal (Fig.D)

To Install the Bit

1. Remove the motor unit from the base unit. Refer to

Removing the Motor from the Fixed Base or Removing

the Motor from the Plunge Base (ifneeded).

2. Clean and insert the round shank of the desired router bit

into the loosened collet as far as it will go and then pull it

out about 1.6mm.

3. Depress the spindle lock button

7

to hold the spindle shaft

in place while turning the collet nut

23

clockwise with the

wrenchprovided.

NOTE: The unit is equipped with multiple spindle lock

detents allowing an optional "manual ratchet" method of

tightening thebit.

To tighten with the "manual ratchet" method:

a. Without removing the wrench from the collet nut

23

release pressure on the spindle lock button

7

b. With the wrench still on the collet nut, reverse the

tightening direction to reset the wrenchposition.

c. Depress the spindle lock button again and turn the

wrenchclockwise.

d. Repeat the procedure until the collet nut reaches

desiredtightness.

NOTICE: Avoid possible damage to the collet. Never

tighten the collet without abit.

To Remove the Bit

1. Remove the motor unit from the base unit (refer to

Removing the Motor from the Fixed Base or Removing

the Motor from the Plunge Base.

2. Depress the spindle lock button

7

to hold the spindle shaft

in place while turning the collet nut

23

anticlockwise with

the wrenchprovided.

To loosen using the "manual ratchet" method:

1. Without removing the wrench from the collet nut

23

release pressure on the spindle lock button

7

2. With the wrench still on the collet nut

23

, reverse the

loosening direction to reset the wrenchposition.

3. Depress the spindle lock button

7

again and turn the

wrenchanticlockwise.

4. Repeat the procedure until the collet nut

23

is loose and

the bit can beremoved.

Collets

NOTE: Never tighten the collet without first installing arouter

bit in it. Tightening an empty collet, even by hand, can damage

thecollet.

To change collet sizes, unscrew the collet assembly as described

above. Install the desired collet by reversing the procedure.

The collet and the collet nut are connected. Do not attempt to

remove the collet from the colletnut.

Locking Lever Adjustment (Fig.E)

Excessive force should not be used to clamp the locking lever.

Using excessive force may damage thebase.

When the locking lever is clamped, the motor should not move

in thebase.

Adjustment is needed if the locking lever will not clamp without

excessive force or if the motor moves in the base afterclamping.

To adjust the locking lever’sclamping force:

1. Open the locking lever

12

(fixed base) or

40

(plungebase).

2. Using ahex wrench turn locking lever adjustment screw

24

in smallincrements.Turning the screw clockwise tightens

the lever, while turning the screw anticlockwise loosens

thelever.

Centreing the Subbase (Fig.A, F1–F3)

If you need to adjust, change, or replace asubbase, acentreing

tool is recommended. The centreing tool consists of acone and

apin.

To adjust asubbase, follow the stepsbelow.

Figure F1 shows adjusting the D-shaped subbase on the

fixed base.

Figure F2 shows adjusting the subbase on the plungebase.

Figure F3 shows adjusting the round subbase on the fixed base.

1. Loosen but do not remove the subbase screws

25

so the

subbase movesfreely.

2. Insert the pin into the collet and tighten the colletnut.

3. Insert the motor into the base and clamp the locking

lever

12

/

40

on thebase.

4. Place the cone on the pin and lightly press down on the

cone until it stops. This will centre thesubbase.

5. While holding down on the cone, tighten the

subbasescrews.

Using Template Guides

The plunge subbase will accept template guides. On the

fixed base, the round subbase will be needed to accept

templateguides.

NOTE: The D-shaped subbase does not accommodate template

guides and is designed to accommodate cutters up to 30mm

indiameter.

To Use Template Guides

1. Install template guide to subbase using two screws and

tightensecurely.

2. Centre the subbase. Refer to Centreing theSubbase.

Installing aFixed Base Parallel Fence (Fig.G)

Aparallel fence (model DE6913) for your fixed base isincluded.

1. Remove the motor from the fixed base. Refer to Removing

the Motor from the FixedBase.

2. Remove flat head screws

27

from storage holes on

parallelfence.

3. Slide parallel fence

26

into parallel fence slot

28

on side of

fixed base (Fig.G). Insert the two flat head screws through

the appropriate holes in the subbase to secure the edge

guide. Tightenhardware.

4. Follow all instructions included with the parallelfence.
