English

WARNING

Use extreme caution when lifting or tilting the product for

maintenance, cleaning, storage or transportation. The

blade is sharp. Even though the engine is shut off, the

blades can still be moved. Keep all body parts away from

the blade while it is exposed.

MAINTENANCE

WARNING

After releasing the power lever, regularly check if the

blade stops in 3 seconds.

WARNING

If the product is not maintained correctly, the life span of

the product may be reduced, and built-in safety features

may not function correctly, thus increasing the potential

for serious injury. Keep the product in good working

condition.

WARNING

Before performing any maintenance, stop the product,

allow the blade to come to a complete stop, and

disconnect the spark plug wire from the spark plug.

Failure to heed this warning could result in serious

personal injury.

WARNING

When servicing, use only authorised replacement parts.

Use of any other parts may create a hazard or cause

product damage.

GENERAL MAINTENANCE

You may make adjustments and repairs described here.

For other repairs, contact the authorised service agent.

■ Avoid using solvents when cleaning plastic parts. Most

plastics are susceptible to damage from various types

of commercial solvents and may be damaged by their

use. Use clean cloths to remove dirt, dust, oil, grease,

etc.

■ Periodically check all nuts and bolts for proper tightness

to ensure safe operation of the product.

■ Remove any buildup of grass and leaves on or around

the engine and engine cover. Occasionally wipe the

mower clean with a dry cloth. Do not use water.

■ Frequently check the grass catcher for wear or

deterioration.

WARNING

Do not, at any time, let brake uids, gasoline, petroleum-

based products, penetrating oils, etc. come in contact

with plastic parts. Chemicals can damage, weaken, or

destroy plastic which may result in serious personal

injury.

CLEANING THE UNDERSIDE OF THE MOWER DECK

1. Raise the mower to full height.

2. Connect a female water hose connector (not supplied)

to the male hose connector on the mower deck.

3. Turn on the water supply.

4. Start the mower and run at full revolutions, but do not

engage the self-propel bail.

5. Run the engine in place for approximately 30 seconds.

6. Shut off the engine.

7. Turn off the water supply.

8. Inspect the underside of the mower deck for cleanliness,

and repeat the cleaning procedure if desired.

LUBRICATION

All of the bearings in the product are lubricated with a

sufcient amount of high grade lubricant for the life of the

product under normal operating conditions. Therefore, no

further bearing lubrication is required.

WARNING

Always protect hands by wearing heavy gloves or wrapping

the cutting edges of the blade with rags and other material,

or both, when performing blade maintenance. Contact

with the blade could result in serious personal injury.

REPLACING THE CUTTING BLADE

See figure 12.

When making adjustments, be careful not to entrap your

ngers between moving blades and xed parts of the

product.

For best results, the mower blade must be kept sharp.

Immediately replace a bent or damaged blade.

WARNING

Only use replacement blades approved by the

manufacturer of the product. Using a blade not approved

by the manufacturer of the product is hazardous and

could result in serious injury, damage to the product, and

will void your warranty.

WARNING

Drain the fuel rst before tilting the product to replace

the blade.
