Specifications

All the specications can be guaranteed if the following two conditions are met unless where noted.

● The generator is within the calibration period and has performed self-calibration.

● The generator has been working continuously for at least 30 minutes under the specied temperature (18

℃

to 28

℃

All the specications are guaranteed unless those marked with “typical”.

Model DG4202 DG4162 DG4102 DG4062

Number of Channels 2 2 2 2

Maximum Frequency 200MHz 160MHz 100MHz 60MHz

Sample Rate 500MSa/s

Waveforms

Standard Waveform Sine, Square, Ramp, Pulse, Noise, Harmonics

Arbitrary Waveform

150 kinds, including Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, HaverSine, Lorentz,

Dual-Tone, DC, etc.

Frequency Characteristics

Sine 1μHz to 200MHz 1μHz to 160MHz 1μHz to 100MHz 1μHz to 60MHz

Square 1μHz to 60MHz 1μHz to 50MHz 1μHz to 40MHz 1μHz to 25MHz

Ramp 1μHz to 5MHz 1μHz to 4MHz 1μHz to 3MHz 1μHz to 1MHz

Pulse 1μHz to 50MHz 1μHz to 40MHz 1μHz to 25MHz 1μHz to 15MHz

Harmonic 1μHz to 100MHz 1μHz to 80MHz 1μHz to 50MHz 1μHz to 30MHz

Noise (-3dB) 120MHz bandwidth 120MHz bandwidth 80MHz bandwidth 60MHz bandwidth

Arbitrary Waveform 1μHz to 50MHz 1μHz to 40MHz 1μHz to 25MHz 1μHz to 15MHz

Resolution 1μHz

Accuracy ±2ppm, 18

℃

to 28

℃

Sine Wave Spectrum Purity

Harmonic Distortion

Typical (0dBm)

DC to 1MHz: <-60dBc

1MHz to 10MHz: <-55dBc

10MHz to 100MHz: <-50dBc

100MHz to 200MHz: <-40dBc

Total Harmonic Distortion <0.1% (10Hz to 20kHz, 0dBm)

Spurious (non-harmonic)

Typical (0dBm)

≤10MHz: <-65dBc

>10MHz: <-65dBc + 6dB/octave

Phase Noise

Typical (0dBm, 10kHz deviation)

10MHz: ≤-115dBc/Hz

Signal Characteristics

Square

Rise/Fall Time

Typical (1Vpp)

<8ns

Typical (1Vpp)

<10ns

Typical (1Vpp)

<12ns

Overshoot

Typical (100kHz, 1Vpp)

<3%

Duty Cycle

≤10MHz: 20.0% to 80.0%

10MHz to 40MHz: 40.0% to 60.0%

>40MHz: 50.0% (xed)

Non-symmetry 1% of period + 5ns

Jitter (rms)

Typical (1MHz, 1Vpp, 50Ω)

≤5MHz: 2ppm + 500ps

>5MHz: 500ps

Ramp
