2. Technical Specification

The manufacturer reserves himself the right to make the manual's content or function

change without any preliminary notification of the users.

torch

3.Application

Th is intended for connection to the power source and for the gas-shielded semiautomatic

consumable electrode welding. The torch enable the possibility of gas-shielded welding with the use

of welding machines.

The torch application is permitted under the following climatic conditions:

a) The ambient temperature:

while welding: –10 … +40°C,

while storing and shipping: - 25 … +55°C.

b) Relative air humidity:

at +40°C – less than 50%,

at +20°C – less than 90%.

is torch

The torch is designed for . While connecting the torch to power source observe the

rules indicated in the machine manual. The rated duty cycle is 60%, this means that within 10-

minutes' cycle the torch temperature reaches acceptable limit. In order to prevent the

insulation failure and premature wear of the torch, it is recommended to use it in rated duty cycle

only. In process of operation it is necessary to monitor the nozzle. The torch nozzle are to be cleaned

of metal spray in proper time and are to be replaced if they are worn. Strong hits can cause

deformation of the nozzle.

! Operation in the mode above the rated is prohibited since it causes the torch

destruction.

plasma cutting

cuting

WARNING

Omperator's anual

- 2 -

Тype FB P40 FB P60 FB P100 FB PA100

Cutting current, А 40 60 100 100

Max voltage, V 110 110 110 110

Duty cycle, % 60 60 100 100

Electrode FP0093, FP0094 FP0093, FP0094 FP2202.6122 FP2202.6122

Nozzle (D), mm 0,8 - 1,0 0,8 - 1,1 0,9 - 1,6 0,9 - 1,6

Cable assembly lengths 6 m 6 m 6 m 12 m
