www.sames-kremlin.com
48
1
2
3
4
5
6
7
Bond | Protect | Beautify
Automatic spray gun
A 35 HPA
Modular design for high volume production
with an excellent nish quality. Wide fan pattern
available.
Power supply Gun base Fittings supplied, non tted
Fluid F 1/4" NPS Quick tting - Ø 6 x 8 hose
Atomization air F 1/4" NPS M 1/4" NPS - air hose Ø 7mm int
Pilot air F 1/8" NPS Quick ttings - air hose Ø 4x6
Maximum air inlet pressure (bar) 6
Maximum uid pressure (bar) 6
Trigger air pressure (bar mini) 3
Recommended atomization air pressure
(bar)
3 - 5
Weight (g) (gun only) 497
Maximum Fluid Temperature (°C) 50
Air consumption (m
3
/h) 33
Wetted parts
Stainless steel - treated stainless
steel
ATEX II2G Ex h IIB T6 Gb X
AVAILABLE GUN CONFIGURATIONS
Type Side outputs Rear outputs
Fluid circulation Circulation in the base (┴)
Circulation in the base
(┴)
Material (base plate)
Aluminum with stainless
steel insert
Aluminum with
stainless steel insert
Weight (g) 240 480
Answers to high production Airspray rates
Designed for high viscosity material
Modular design & high reliability
SPECIFICATION BASE FOR A35 HPA GUNS
FITTINGS
Spray Technology Gun name Aircap Nozzles size (mm) Base type
Part number with
base
Part number
without base
CONV
(HPA)
A35 HPA w/o projector,
w/o base
- - - - 129.305.000
A35 HPA GUN 06 EN3L
EN 3L
0.6
Side outputs
135.305.106
135.305.006
Rear utputs
135.305.206
A35 HPA GUN 07 EN3L 0.7
Side outputs
135.305.101
135.305.001
Rear utputs
135.305.201
A35 HPA GUN 09 EN3L 0.9
Side outputs
135.305.102
135.305.002
Rear utputs
135.305.202
A35 HPA GUN 12 EN3L 1.2
Side outputs
135.305.103
135.305.003
Rear utputs
135.305.203
A35 HPA GUN 15 EN3L 1.5
Side outputs
135.305.104
135.305.004
Rear utputs
135.305.204
A35 HPA GUN 18 EN3L 1.8
Side outputs
135.305.105
135.305.005
Rear utputs
135.305.205
