85
www.sames-kremlin.com
Airspray spraying & equipment
Catalog V5.3
Spray gunsMachines & Controllers PumpsAccessoriesGeneral informations
Fluid regulators and lters
LOW PRESSURE REGULATOR - MANUAL CONTROL
Manual control
Manual drive and integrated pilot
LOW PRESSURE REGULATOR - MANUAL DRIVE AND INTEGRATED PILOT
Made entirely out of stainless steel, easy to ush.
The regulator with manual drive and integrated pilot is designed for an easy ushing.
AVAILABLE REGULATOR CONFIGURATION
Description
Stainless steel
ball
Manometer Part number
Bare pressure regulator PP (small passage) Ø 5 - 155.610.200
Pressure regulator PP (small passage) Ø 5
●
155.610.209
Bare pressure regulator GP (large passage) - charged materials Ø 9 - 155.610.250
Pressure regulator GP (large passage) - charged materials Ø 9
●
155.610.259
Regulator bracket 155.610.576
FITTINGS
Passage size Small Large
Fluid inlet F ¼’’ NPS M ¼’’ BSP (w/o adaptator)
Fluid outlet F ¼ ‘’ BSP (x2) F ¼ ‘’ BSP (x2)
SPECIFICATIONS
Pressure range (bar) Inlet 40 max.
Outlet (upon version) 0.5 - 4
Weight (kg) 1.3
Width (cm) 8.5
Height (cm) Large passages 17
Small passage 16.5
Wetted parts Stainless steel, PTFE, carbide
FITTINGS
Fluid Inlet M 1/4" BSP + (M18x125, M3/8" NPS, M3/8"BSP)
Fluid Outlet F 1/4" BSP
SPECIFICATIONS
Pressure (bar) Inlet 10 max
Outlet 4 max
Width (cm) 20
Height (cm) 8.5
Wetted parts Stainless steel, PTFE, carbide
AVAILABLE REGULATOR CONFIGURATION
Description Weight (kg)
Stainless steel
ball
Material Part number
Low pressure regulator with integrated pilot 1.6 Ø 9 Stainless steel 155.610.060
Regulator bracket 016.200.010
Piloted regulator manual drive and integrated pilot
