8.
Electric air conditioner. Split system
9.
Electric air conditioner. Split system
EN EN
REMOTE CONTROL
Indication of the control board display shall
correspond to selected modes.
Work with remote control board
Mounting and replacement of batteries: mount two LR03 alkaline batteries, according to polarity
indicated on the remote control board.
In order to avoid malfunction of the remote control board do not insert used batteries or batter-
ies of various types.
If the conditioner is not used for a long time, remove batteries from the board or else electrolyte
may leak and damage the board.
In normal operation of the conditioner average service life of batteries will be about a half-year.

does not show a sign of command transfer. When generating commands from the remote con-
trol board, point an IR-radiator at a remote-control signal receiver situated on the indoor unit.
Hold the remote control board at the distance of no more than 8 m from the indoor unit. The re-
mote control board will not work, if there are any curtains, doors or other things between it and
the indoor unit. Protect the board from water and exposure to direct sunlight and heat sources.
7. OPERATING MODES
«AUTO» mode
» on the remote control
board.
1. During operation in the AUTO mode, the set temperature is maintained. In this mode, the air
conditioner automatically selects the COOLING, VENTILATION, or HEATING mode based on the
set and current temperatures.
2. In the automatic mode, the fan rotation speed is selected automatically and cannot be set
manually.
3. If the AUTO mode does not provide comfort conditions, select the mode manually. In auto-
matic mode, depending on air temperature in the room, the conditioner will select needed
temperature parameters of its operation in the following order:
«COOL», «HEAT» and «FAN»
1. » button.
2. » button, select COOL, HEAT or FAN mode manually.
3. » button (up-down), set the desired air temperature indoors (except for
FAN mode).
4. » button on the remote control board, select the fan rotation speed:
AUTO, LOW, MIDDLE, HIGH, and the conditioner will start working in accordance with the
selected setting.
5. » button once again.
In the «FAN» mode air temperature indoors is not set.
«DRY»
»» button, select the

» button once again.
13
12
11
10
2
4
6
5
7
3
1
8
9
2. Forced cooling. The operation indicator blinks and the air conditioner works in the forced
cooling mode. The fan speed is high for 30 min. The remote controller cannot be used.
3. 
controller can be used.
Fig. 4
1. 

2. 
the required air temperature from 17 to

required air temperature indoors.
3. 

4. 
button, you may select a required mode:
Auto, Cool, Dry, Heat, Fan.
5. 
activate the economy mode. Press it
once again to deactivate the mode. This
function can be activated in the Cooling,
Heating, and Auto modes.

or MODE button is pressed, this mode is
automatically deactivated.
6. 
button, you may regulate position of
air-relief blinds and forward treated air
to up and down.
7. 
can may to clear the display on the indoor
unit. Press it again to light the display.
8. 
button, you may regulate position of
air-relief blinds and forward treated air

9. 
10. 

of the button increases the timer setting
by 30 min. When the reading reaches 10
hours, each pressing will increase the
timer setting by 60 min. To deactivate
the automatic timer function, set the
value at 0.0.
11. 
initiate the on-delay timer. Each pressing
of the button increases the timer setting
by 30 min. When the reading reaches 10
hours, each pressing will increase the
timer setting by 60 min. To deactivate
the automatic timer function, set the
value at 0.0.


12. 
may select rotation speed of the indoor

13. 
the required air temperature from 17 to

required air temperature indoors.
