инструкция по эксплуатации станка JET мод. BD-7

186 ........... Washer ..................................................... шайба .................................................... 5 ...................... 1

187 ........... Key ........................................................... шпонка .................................................. 3*16 ................ 1

188 ........... Spacer ...................................................... распорка ................................................ ......................... 1

190 ........... Sprinq ...................................................... пружина ................................................ ......................... 2

191 ........... Washer ..................................................... шайба .................................................... 8 ...................... 1

192 ........... Spring washer .......................................... пружинная шайба ................................. 6 ...................... 2

193 ........... Screw ....................................................... винт ....................................................... M8*55 ............. 2

194 ........... Screw ....................................................... винт ....................................................... M4*38 ............. 1

195 ........... Nut ............................................................ гайка ...................................................... M4 ................... 1

196 ........... Tailstock plate ......................................... пластина задней бабки......................... ......................... 1

197 ........... Screw ....................................................... винт ....................................................... M 5* 16 ........... 1

198 ........... Flange ...................................................... фланец ................................................... ......................... 1

199 ........... Screw ....................................................... винт ....................................................... M5*25 ............. 1

200 ........... Key .......................................................... шпонка .................................................. 3*12 ................ 1

201 ........... Chuck protect cover ................................. защитный кожух патрона .................... ......................... 1

202 ........... Hinge ....................................................... петля ...................................................... ......................... 1

208 ........... Washer ..................................................... шайба .................................................... 5 ...................... 1

209 ........... Screw ....................................................... винт ....................................................... M3*6 ............... 4

210 ........... Cover ....................................................... кожух ..................................................... ......................... 1

211 ........... Screw ....................................................... винт ....................................................... M5* 16 ............ 2

212 ........... Fix base .................................................... неподвижное основание ...................... ......................... 1

213 ........... Pin ............................................................ шплинт .................................................. 4*50 ................ 1

214 ........... Screw ....................................................... винт ....................................................... M2* 12 ............ 1

215 ........... Micro switch ............................................. микровыключатель .............................. ........................ 1

216 ........... screw ........................................................ винт ....................................................... M6*8 ............... 2

217 ........... Motor fixed plate ..................................... площадка двигателя ............................. ......................... 1

218 ........... Washer ..................................................... шайба .................................................... 6 ...................... 1

219 ........... Spacer ...................................................... распорка ................................................ ......................... 1

220 ........... light beam ................................................ лампочка ............................................... ......................... 1

221 ........... Spacer ...................................................... распорка ................................................ ......................... 1

232 ........... Screw ....................................................... винт ....................................................... M4*6 ............... 3

233 ........... Photoelectricity switch ............................ выключатель ......................................... ......................... 1

234 ........... Screw ....................................................... винт ....................................................... M3*8 ............... 2

250 ........... Nut ........................................................... гайка ...................................................... M6 ................... 1

251 ........... Compression spring ................................. пружина сжатия ................................... ......................... 1

252 ........... Dial .......................................................... круговая шкала ..................................... ......................... 1

253 ........... Screw ....................................................... винт ....................................................... ST2.9*10 ........ 2

254 ........... Cover ....................................................... кожух ..................................................... ......................... 1

255 ........... Screw ....................................................... винт ....................................................... M4*8 ............... 2

256 ........... Nut ........................................................... гайка ...................................................... M6 ................... 1
