11

Components

Overview (fig. I)

1 Handle

2 LCD

3 Infrared sensor

4 Actuator (measurement button)

5 Battery cover

Indicator

6 Temperature values for MAX

7 Symbol for MAX

8 Currently measured value

9 Display of measured value

10 Data hold

11 Symbol laser on/o

12 Symbol lock

13 High/low alarm symbols (HAL; LOW)

14 Symbols for °C / °F

15 Low battery symbol

16 Symbol and value for emissivity

Keys

17 Down key (lighting (on/o))

18 Mode key (menu loop)

19 Up key (laser on/o)

Function overview

• Precise non-contact measurements

• The excellent optical system allows measure-

ments even from long distances

• Wide temperature measurement range

• Double laser pointer

• MAX-HOLD-LOCK function

• Adjustable emissivity

• Optical and acoustical alarm if the tempera-

ture falls below the freely adjustable values or

if it exceeds them

• Backlight

• Possibility to select °C/°F

Technical specications

Item 0715 53 110

Measuring range -50 °C - 650 °C

(-58 °F - 1202 °F)

Optical resolution D:S 12:1

Display resolution 0.1 °C

Precision

(ambient temperature from 23°C - 25°C)

-50 °C ~ 20 °C ± 2.5 °C

20 °C ~ 300 °C ± 1.0 % ± 1.0 °C

300 °C ~ 650 °C ± 1.5 %

Reproducibility

-50 °C ~ 20 °C ± 1.3 °C

20 °C ~ 650 °C ± 0.5 °C

Response time 150 ms

Spectral responsitivity 8 ~ 14 μm

Operating temperature 0 - 50 °C

Storage temperature -10 - 60 °C

Laser Class II

Emissivity adjustable from 0.10

to 1.0

Power supply 1 x 9 V battery

Relative humidity

10 % ~ 90 % RH (operation)

< 80 % RH (storage)
