File Name:NTS-750-SPEC 2023-04-27
SPECIFICATION
38A
90%
19A
91%
38A
93%
19A
93%
MODEL NO.
OVER RATED POWER(3 Min.)
PEAK POWER(10 Sec.)
SURGE POWER(30 Cycles)
WAVEFORM Note.1
AC OUTPUT
FREQUENCY
AC REGULATION
VOLTAGE RANGE (Typ.)
EFFICIENCY (Typ.) Note.1
DC CURRENT (Typ.)
DC INPUT
DC INPUT
AC OUTPUT
ENVIRONMENT
FUSE (Internal)
SAFETY
&
EMC
LOW
HIGH
OVER TEMPERATURE
OUTPUT SHORT
BAT. POLARITY
GFCI PROCTECTION
PROTECTION
True sine wave (THD<3%)
75A
90%
40A*3 40A*2 25A*2
25A*240A*2
±3.0% at rated output voltage
89%
75A
40A*3
Protection type : Shut down o/p voltage, re-power on to recover(except 112/124GFCI)
Shut down o/p voltage,recovers automatically after temperature goes down(for 112/124GFCI)
Protection type : Shut down o/p voltage, re-power on to recover
By internal fuse open
None
-25 ~ +70 (Refer to “Derating curve”)℃
WORKING TEMP.
REMOTE
CONTROL
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
Remote controller sold separately, Order No.: IRC1,IRC2,IRC3
20% ~ 90% RH non-condensing
-30 ~ +70 / -22 ~ +158 F, 10 ~ 95% RH non-condensing℃
o
RATED POWER(Continuous) 750W
OVER LOAD (Typ.)
105 ~ 115% load for 180 sec., 115% ~ 150% load for 10 sec.
Protection type : Shut down o/p voltage, re-power on to recover
UL458 (Only for “GFCI” AC socket, by request)
WITHSTAND VOLTAGE
DC I/P - AC O/P:3.0KVac AC O/P - FG:1.5KVac
VIBRATION
10 ~ 500Hz, 3G 10min./1cycle, 60min. each along X, Y, Z axes
OTHERS
PACKING
2.3Kg; 4pcs/ 10.2Kg/ 1.9CUFT
MTBF
DIMENSION
270*158*67mm (L*W*H)
NOTE
862W
1125W
1500W
FRONT PANEL LED
24V 48V 24V 48V
DC VOLTAGE 12V12V
OFF MODE CURRENT DRAW ≦1mA
BATTERY TYPES
Lead Acid or li-ion
AC VOLTAGE
100 / 110 / 115 / 120Vac selectable by DIP S.W
Default setting set at 110VAC
200 / 220 / 230 / 240Vac selectable by DIP S.W
Default setting set at 230VAC
FUNCTION
ALARM
SHUTDOWN
RESTART
ALARM
SHUTDOWN
RESTART
ACCESSORY
DRY CONTACT
= US, GFCI, UN = EU, CN, AU, UK, UN
NTS-750 series
750W High Reliable True Sine Wave DC-AC Power Inverter
NTS-750-112 NTS-750-124 NTS-750-148 NTS-750-212 NTS-750-224 NTS-750-248
11 0.3Vdc±
22 0.5Vdc± 44 1Vdc±44 1Vdc±22 0.5Vdc±
10 0.3Vdc± 20 0.5Vdc± 40 1Vdc±40 1Vdc±20 0.5Vdc±
11 0.3Vdc±
10 0.3Vdc±
Power ON-OFF remote control by front panel dry contact connector (by RELAY), Open : Normal work ; Short : Remote off
1.Efficiency, AC regulation and THD are tested by 600W, linear load at 12.5Vdc/25Vdc/50Vdc input voltage.
2.All parameters not specified above are measured at rated load, 25 of ambient temperature and set to factory setting.
℃
3.Internal pre-start circuit, the setup time is 8s.
4.The power supply is considered as an independent unit, but the final equipment still need to re-confirm that the whole system complies with the
EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.
(as available on http://www.meanwell.com)
※ Product Liability Disclaimer For detailed information, please refer to ： https://www.meanwell.com/serviceDisclaimer.aspx
20 ~ 33Vdc
40 ~ 66Vdc
20 ~ 33Vdc
40 ~ 66Vdc10 ~ 16.5Vdc10 ~ 16.5Vdc
12.5 0.3Vdc±
15.5 0.3Vdc±
16.5 0.3Vdc±
15 0.3Vdc±
25 0.5Vdc±
31 0.5Vdc±
33 0.5Vdc±
30 0.5Vdc±
12.5 0.3Vdc±
15.5 0.3Vdc±
16.5 0.3Vdc±
15 0.3Vdc±
50 1Vdc±
62 1Vdc±
66 1Vdc±
60 1Vdc±
50 1Vdc±
62 1Vdc±
66 1Vdc±
60 1Vdc±
25 0.5Vdc±
31 0.5Vdc±
33 0.5Vdc±
30 0.5Vdc±
Please see page5
EMC IMMUNITY
EMC EMISSION
Parameter
Parameter
Radiated
Standard
Standard
FCC for 112,124,148 only(expect for Type-UN)
BS EN/EN55032(CISPR32) for 212,224,248 only(expect for Type-UN)
Test Level / Note
Test Level / Note
Class A
Class A
Harmonic Current
Voltage Flicker
BS EN/EN61000-3-2
BS EN/EN61000-3-3
-----
-----
ESD
Radiated
Magnetic Field
BS EN/EN61000-4-2
BS EN/EN61000-4-3
BS EN/EN61000-4-8
Level 3, 8KV air ; Level 2, 4KV contact
Level 2, 3V/m
Level 1, 1A/m
Default 50Hz 0.1Hzsetting set at ±
Default 60Hz 0.1Hz
setting set at ±
50/60Hz selectable by DIP S.W 50/60Hz selectable by DIP S.W
SAFETY STANDARDS
NO LOAD
DISSPATION
(Typ.)
NON-SAVING MODE
SAVING MODE
Default disable, 1.2W ~ 1.5W by models @ auto detect AC output load 10W will be changed to saving mode≦≦
10W 12W
10W
10W 12W
10W
1.4W 1.5W
1.2W
1.4W 1.5W
1.2W
715.7K hrs min. Telcordia TR/SR-332 (Bellcore) ; 78K hrs min. MIL-HDBK-217F (25 )℃
CB IEC62368-1,Dekra BS EN/EN62368-1,UL458, E13,EAC TP TC 004 approved;Design refer to AS/NZS 62368.1
(Please refer to next page )
“AC output socket” table for more details
BS EN/ BS EN/EN55024, EN55035
(Note.4)
RS-232 COMMUNICATION
RS-232 ~ RJ11 Type connector (Please refer to page )4 for more details
