File Name:NTS-750-SPEC 2023-04-27
MECHANICAL SPECIFICATION
Unit:mm
NTS-750 series
750W High Reliable True Sine Wave DC-AC Power Inverter
direction
Air flow
Type-EU
Type-US
Type-CN
(AC output side)
Type-UN
(DC input side)
1 2
Chassis
Bonding
Lug
67
Reverse Polarity Will
Damage The Unit.
ON
OFF
DC INPUT
+
-
45
180
270
147
158
9
16
7
R.C Connector : JST B-XH or equivalent
Remote Control Mating Housing
JST XHP
JST SXH-001T
or equivalent
or equivalent
Terminal
Pin 1,2 Open: Normal work
Pin 1,2 Short: Remote off
SW
R.C
Load
DC input
Status
Remote port
AC OUTPUT
SW
R.C
Remote port
Load
DC input
Status
AC OUTPUT
1 2
SW
R.C
Load
DC input
Status
Remote port
1 2
AC OUTPUT
1 2
SW
R.C
Load
DC input
Status
Remote port
AC OUTPUT
Remote port connector (RJ11)
Remote port
2
DB9
3
4
3
5
2
Remote port
Assignment
Rx
GND
Tx
