SPECIFICATION

MODEL

OUTPUT VOLTAGE Note.2

OUTPUT

LINE REGULATION

LOAD REGULATION

HOLD UP TIME (Typ.)

VOLTAGE RANGE

FREQUENCY RANGE

POWER FACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

INRUSH CURRENT (Typ.)

BATTERY CUT OFF

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

OPERATING ALTITUDE Note.8

OVER VOLTAGE CATEGORY

DIMENSION

OTHERS

NOTE

OVERLOAD

OVER VOLTAGE

AC CURRENT (Typ.)

90 ~ 127 ~ 431VDC 305VAC

COLD START 30A/115VAC 60A/230VAC

-30 ~ +70℃(Refer to “Derating Curve")

20 ~ 90% RH non-condensing

-40 ~ +85℃, 10 ~ 95% RH non-condensing

±0.03%/℃ (0 ~ 50℃) on Load output

10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes

2000 meters / OVCⅢ

Ⅲ; According to Dekra BS EN/EN62368-1; altitude up to 2000 meters

556.6K hrs min. Telcordia SR-332 (Bellcore); 74.5K hrs min. MIL-HDBK-217F (25℃)

PF>0.95/230VAC PF>0.98/115VAC at full load

16ms/230VAC 10ms/115VAC at full load

VOLTAGE TOLERANCE Note.6

℃













℃℃











※ https://www.meanwell.com/serviceDisclaimer.aspx：

ENVIRONMENT

PROTECTION

110*125.2*150.7mm (W*H*D)

Protection type : Shut down o/p voltage, re-power on to recover

5.4A/115VAC 2.7A/230VAC

LOAD CURRENT RANGE

TOTAL OUTPUT POWER Note.4

RIPPLE & NOISE (max.) Note.5

1.65Kg; 6pcs/ 11Kg / 1.42CUFT

47 ~ 63Hz

Protection type: Constant current limiting, shutdown output voltage after 5 sec.

FUNCTION

AC FAIL

BATTERY LOW/

ABNORMAL/

DISCONNECTED

Signals AC failure and activates when input voltage drops below : 79~89VAC of 120AC, 132~187VAC of 220VAC.

Relay contact output, ON : AC OK ; OFF : AC Fail ; max. rating : 30Vdc/1A

Relay contact output, ON : Battery OK ; OFF : Battery Low ; max. rating : 30Vdc/1A

Battery low voltage : < 22V±0.3V Battery low voltage : < 33V±0.4V Battery low voltage : < 44V±0.5V

SAFETY STANDARDS

SAFETY &

EMC

(Note.10)

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

I/P-O/P: 4KVAC I/P-FG: 2KVAC O/P-FG: 1.5KVAC

I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC/25℃/ 70%RH

UL62368-1, Dekra BS EN/EN62368-1, RCM AS/NZS 62368.1 approved; pendingEAC TP TC 004

±0.5% ±0.5% ±0.5%

±1.0% ±1.0% ±1.0%

Load main output : 32.4 ~ 37.3V Load main output : 48.6 ~ 55.9V Load main output : 64.8 ~ 74.5V

Combined power on all Channels must not exceed 480W, load has priority. 550W peak capability within 5s.

MTBF

PACKING

240mVp-p 360mVp-p

92.5% 93.5%

20.9±0.5V 31.3±0.7V

DRS-480-24 DRS-480-36

24V 36V

0 ~ 20A 0 ~ 13.3A

EMC IMMUNITY

EMC EMISSION

Parameter

ESD

Radiated

EFT / Burst

Surge

Conducted

Magnetic Field

Conducted

Radiated

Harmonic Current

Voltage Flicker

BS EN/EN55035 , BS EN/EN61204-3, BS EN/EN61000-6-2(BS EN/EN50082-2)

Standard

BS EN/EN55032 (CISPR32)

BS EN/EN61000-4-2

BS EN/EN61000-4-3

BS EN/EN61000-4-4

BS EN/EN61000-4-5

BS EN/EN61000-4-6

BS EN/EN61000-4-8

Test Level / Note

Level 3, 8KV air ; Level 2, 4KV contact; criteria A

Level 3, 10V/m ; criteria A

Level 3, 2KV ; criteria A

Level 3, 1KV/Line-Line ;Level 3, 2KV/Line-Line-Chassis ;criteria A

Level 3, 10V ; criteria A

Level 4, 30A/m ; criteria A

Class B

-----

DC OK

CHARGER FAIL

Signals normal DC output and activates when output voltage > 90% rated value.

Relay contact output, ON : DC OK ; OFF : DC Fail ; max. rating : 30Vdc/1A

Relay contact output, ON : Charger OK ; OFF : Charger Fail ; max. rating : 30Vdc/1A

REVERSE POLARITY

FORM-C

RELAY

DC-UPS

ADJUSTABLE CHARGING CURRENT

UPS switch to battery power within 10ms of AC failure

20% ~ 100% charging current adjustable by VR

By internal MOSFET, , recovers automatically after fault condition is removed.no damage

BATTERY START Restart system directly from battery and does not require AC power

RECOMMENDED BATTERY

CAPACITY(AMP HOURS)Note.3

20 ~ 200AH 13 ~ 133AH 10 ~ 100AH

OVER TEMPERATURE

Automatically drop load with temperature only for bat. load.

Protection type : Shut down o/p voltage, recover automatically after temperature goes down.

BATTERY CURRENT (CC)(max.)

7.7A

15.4A 10.2A

SETUP RISETIME Note.7

2400ms, 1000ms/230VAC 2400ms, 1000ms/115VAC at full load

BS EN/EN61000-3-2

SHORT CIRCUIT

Protection type: Constant current limiting, power will shutdown after 5 sec, re-power on to recover.

DRS-480 series

480W All-In-One Intelligent Security Power

FIRE DETECTION AND

FIRE ALARM SYSTEM

Compliance to BS EN/EN54-4

BATTERY TEMPERATURE

COMPENSATION

The system can change the battery charging voltage by detecting the temperature (Please refer to page 9~10 for more details).

File Name:DRS-480-SPEC 2022-05-05
