Safety instructions

■

Use only rubber-sheathed cables of quality

H05RN-F according to DIN57282, Part 817 /

VDE0282, Part 817 with a rubber-coated

plug connector and a conductor cross section

of at least 1.5mm² (230V: 3x1.5mm²,

400V: 5x1.5mm²). The cable must not be

of a lighter type.

For the United Kingdom only: rubber-

sheathed cables of type BS6500 (1984), Ta-

ble 16 PVC 3 core flex, 300/500V HOS VV-F

with a rubber-coated plug connector and a

13A fuse.

■

The maximum permissible cable length is

50m. A longer cable impairs the motor power

and hence the performance and function of

the log splitter.

■

Mains cable, mains plug and coupling socket

must be undamaged. A defective mains ca-

ble (e.g. with cracks/fractures, cuts, crushed

or kinked points in the insulation) must not be

used.

■

Check the condition of your mains cable each

time prior to use.

■

Protect the mains cable from heat and sharp

edges. Do not expose plug connectors to

moisture.

■

Do not pull on the mains cable to remove the

mains plug from the socket.

■

If the mains cable is damaged, immediately

disconnect it from the mains.

■

Repairs to the mains cable, mains plug and

coupling socket may only to be carried out by

qualified electricians.

3.7 Product overview(01)

MH 2810

No. Component

1 Handle

2 Locking screw

3 On-switch

4 Off-switch

5 Venting slots

6 Transport wheels

7 Base

8 Socket

9 Switch for overload protection

No. Component

10 Hopper

11 Upper shredder part with feed chute

12 Grass catcher lock

13 Fangbox

14 Feet

LH 2810

No. Component

1 Handle

2 Feed chute

3 Direction of rotation selector

4 Switch for overload protection

5 Adjusting screw for counterplate

6 Socket

7 Base

8 Transport wheels

9 Feet

10 Fangbox

11 Grass catcher lock

12 Venting slots

13 Off-switch

14 On-switch

15 Hopper

3.8 Scope of supply

The scope of supply of the machine comprises

the following components:

■

Base with collector box

■

Shredder upper section with shredder mech-

anism and motor

■

Hopper

■

Two transport wheels with wheel caps

■

Bag with assembly parts and operating in-

structions

4 SAFETY INSTRUCTIONS

Operator:

■

Persons under the influence of alcohol, drugs

or medication are not allowed to use the ma-

chine.
