10 English

Safety devices

몇 CAUTION

Missing or modified safety devices!

Safety devices are provided for your own protection.

Do not bypass, remove or render ineffective any safety

devices.

Power switch

The power switch prevents unintentional operation of

the device.

High-pressure gun lock

The lock locks the lever of the high-pressure gun and

prevents the device from starting unintentionally.

Auto-stop function

If the lever of the high-pressure gun is released, the

pressure switch turns off the pump and the high-pres-

sure jet stops. The pump switches on again when the le-

ver is pressed.

Symbols on the device

Installation

For the illustrations, refer to the graphics page.

Fit the supplied loose parts onto the device before start-

ing up the device.

Place the screws provided and matching screwdriver at

the ready.

Installing the wheels

1. Install the wheels on the device so that they latch in-

to place.

Illustration B

Mounting the transport handle

1. Attach the transport handle.

2. Secure the transport handle with 4 screws.

Illustration C

Mounting the storage option for the high-

pressure gun

1. Push in the storage option for the high-pressure gun

into the holder on the device.

2. Hold the storage option in the end position and se-

cure it using a screw.

Illustration D

Mounting the storage option for spray lances

1. Push in the storage option for the spray lances into

the holder on the device.

2. Hold the storage option in the end position and se-

cure it using a screw.

Illustration E

Installing the water connection coupling

1. Screw the water connection coupling onto the water

connection on the device.

Illustration F

Initial startup

1. Place the device on a flat and level surface.

2. Unwind the high-pressure hose and eliminate any

loops and twists.

3. Connect the high-pressure hose to the device.

a Pull up the clamp on the coupling.

b Insert the high-pressure hose into the coupling.

c Press down the clamp on the coupling.

Illustration G

4. Connect the high-pressure hose to the high-pres-

sure gun.

a Squeeze the clamp.

b Pull out the clamp.

c Insert the high-pressure hose.

d Press the clamp in until it latches into place.

Illustration H

5. Check for a secure connection by pulling on the

high-pressure hose.

6. Plug the mains plug into a mains socket.

Water supply

For the connection values, see the type plate or chapter

Technical data.

Observe the water distribution company regulations.

ATTENTION

Damage through contaminated water

Contamination in the water can damage the pump and

the accessories.

KÄRCHER recommends using the KÄRCHER water fil-

ter for protection(special accessory, order number

4.730-059).

Connection to the water line

ATTENTION

Hose coupling with Aquastop on the water connec-

tion of the device

Damage to the pump

Never use a hose coupling with Aquastop on the water

connection of the device.

You can use an Aquastop coupling on the tap.

1. Plug the garden hose onto the water connection

coupling.

2. Connect the garden hose to the water line.

Illustration I

3. Open the water tap fully.

Operation

ATTENTION

Pump running dry

Damage to the device

If pressure does not build up in the device after 2 min-

utes then switch the device off and proceed according

to the instructions in chapter Troubleshooting guide.

High-pressure operation

ATTENTION

Damage to painted or sensitive surfaces

Surfaces can be damaged when the jet is too close to

the surface or an unsuitable spray lance is used.

Maintain a minimum spray distance of 30 cm when

cleaning painted surfaces.

Do not clean car tyres, paint or sensitive surfaces such

as wood with the dirt blaster.

1. Insert a spray lance into the high-pressure gun and

lock it by turning it 90°.

Illustration J

2. Switch the device on ("I/ON").

3. Unlock the lever of the high-pressure gun.

4. Press the lever of the high-pressure gun.

The device switches on.

Do not aim the high-pressure jet may at per-

sons, animals, live electrical equipment or

the device itself.

Protect the device against frost.

The device may not be connected to the

public drinking water network.
