109

1-7. Safety information

Before driving

UK_AURIS_EE

Airbag system components

The main SRS airbag system components are shown above. The

SRS airbag system is controlled by the airbag sensor assembly. The

airbag sensor assembly consists of a safing sensor and an airbag

sensor.

In certain types of severe frontal or side impacts, the SRS airbag sys-

tem triggers the airbag inflators. A chemical reaction in the inflators

quickly fills the airbags with non-toxic gas to help restrain the motion

of the occupants.

Driver’s knee airbag

(if equipped)

Airbag manual on-off switch

Front passenger airbag

Curtain shield airbags

(if equipped)

Side airbags

Passenger airbag indicator

light

Curtain shield airbag sen-

sors (if equipped)

SRS warning light

Driver airbag

Vehicles with curtain shield

airbags: Side and curtain

shield airbag sensors

Vehicles without curtain

shield airbags: Side airbag

sensors

Airbag sensor assembly

Front airbag sensors
