451

4-3. Do-it-yourself maintenance

Maintenance and care

UK_AURIS_EE

32 IG2 15 A

Multiport fuel injection system/

sequential multiport fuel injection

system, starting system, smart

entry & start system, IGN, METER

33 HTR SUB NO. 1

30 A

Air conditioning system

50 A

34 HTR SUB NO. 2 30 A Air conditioning system

35 HTR SUB NO. 3 30 A Air conditioning system

36 ABS NO. 2 30 A

Anti-lock brake system, vehicle sta-

bility control system

37 STV HTR

25 A Power heater

38 WIP-S 7.5 A

Charging system

39 IG2 NO. 2 7.5 A

Starting system, smart entry & start

system

40 EFI NO. 2 10 A

Multiport fuel injection system/

sequential multiport fuel injection

system

41 EFI NO. 1 10 A

Multiport fuel injection system/

sequential multiport fuel injection

system

42 H-LP RH HI 10 A Right-hand headlight (high beam)

43 H-LP LH HI 10 A Left-hand headlight (high beam)

44 H-LP RH LO

10 A

Right-hand headlight (low beam)

15 A

45 H-LP LH LO

10 A

Left-hand headlight (low beam)

15 A

Fuse Ampere Circuit
