130

1-8. Safety information

UK_AURIS_HV_EE

Airbag system components

The main SRS airbag system components are shown above. The

SRS airbag system is controlled by the airbag sensor assembly. The

airbag sensor assembly consists of a safing sensor and an airbag

sensor.

In certain types of severe frontal or side impacts, the SRS airbag sys-

tem triggers the airbag inflators. A chemical reaction in the inflators

quickly fills the airbags with non-toxic gas to help restrain the motion

of the occupants.

Driver’s knee airbag

Airbag manual on-off switch

Front passenger airbag

Curtain shield airbags

Side airbags

Airbag manual on-off indi-

cator

Curtain shield airbag sen-

sors

SRS warning light

Driver airbag

Side and curtain shield air-

bag sensors

Airbag sensor assembly

Front airbag sensors
