405

4-3. Do-it-yourself maintenance

Maintenance and care

UK_AURIS_HV_EE

13 TURN & HAZ 10 A Turn signal lights

14 ETCS 10 A

Multiport fuel injection system/

sequential multiport fuel injection

ABS MAIN

NO.1

20 A Brake system

16 P/I 2 40 A

Horn, left-hand headlight (low

beam), right-hand headlight (low

beam), back-up lights, “touch

screen”, auto anti-glare inside rear

view mirror, Toyota parking assist-

sensor

17 ABS MTR 1 30 A Brake system

18 ABS MTR 2 30 A Brake system

19 H-LP HI MAIN 20 A H-LP LH HI, H-LP RH HI

20 P CON MTR 30 A P position control system

21 P/I 1 60 A EFI MAIN, BATT FAN, IG2

22 EPS 60 A Electric power steering

23 PCU 10 A Hybrid system

24 IGCT NO.2 10 A

Hybrid system, P position control

system, hybrid battery

25 MIR HTR 10 A

Outside rear view mirror defoggers,

outside rear view mirrors

26 RAD NO.1 15 A Audio system, “touch screen”

27 DOME 10 A

Interior light, personal lights, vanity

lights, smart entry & start system,

luggage compartment light

28 ECU-B 10 A

Gauge and meters, vehicle stability

control system, main body ECU

29 H-LP LH HI 10 A Left-hand headlight (high beam)

30 H-LP RH HI 10 A Right-hand headlight (high beam)

Fuse Ampere Circuit
