153

When driving

TMC corolla_EE

2-2. Instrument cluster

Gauges and meters

 Optitron type meters

Vehicles without a smart entry & start system

The following gauges, meters and displays illuminate when the

engine switch is in the “ON” position.

Vehicles with a smart entry & start system

The following gauges, meters and displays illuminate when the

“ENGINE START STOP” switch is in IGNITION ON mode.

Tachometer

Displays the engine speed in revolutions per minute.

Fuel gauge

Displays the quantity of fuel remaining in the tank.

Engine coolant temperature gauge

Displays the engine coolant temperature.

Speedometer

Displays the vehicle speed.

Multi-information display

P. 164
