171
6
COROLLA_COROL-
LA_HV(TMUK)_Navi_(EE)
6-1. Rear view monitor system
Peripheral monitoring system
The distance guide lines are dis-
played according to flat surfaced
objects (such as the road). It is not
possible to determine the position
of three-dimensional objects (such
as vehicles) using the vehicle width
guide lines and distance guide
lines. When approaching a
three-dimensional object that
extends outward (such as the flat-
bed of a truck), be careful of the fol-
lowing.
■
Vehicle width guide lines
Visually check the surroundings
and the area behind the vehicle. In
the case shown below, the truck
appears to be outside of the vehicle
width guide lines and the vehicle
does not look as if it hits the truck.
However, the rear body of the truck
may actually cross over the vehicle
width guide lines. In reality if you
back up as guided by the vehicle
width guide lines, the vehicle may
hit the truck.
Vehicle width guide lines
■
Distance guide lines
Visually check the surroundings
and the area behind the vehicle. On
the screen, it appears that a truck is
parking at point . However, in
reality if you back up to point ,
you will hit the truck. On the screen,
it appears that is closest and
is farthest away. However, in reality,
the distance to and is the
same, and is farther than and
.
When approaching
three-dimensional objects
A
B
A
A
C
A
C
B
A
C
