240mm

120mm x1

120mm

120mm x2 140mm x2

120mm x2

120mm x3 140mm x2

Front: 120mm x2(included)

Top: 120/140mm x2(optional)

Rear: 120mm x1(included)

PSU Cover: 120mm x2(optional)

Fan Cooling System:

Liquid Cooling System:

Front: 120/140/240/280/360mm

Top: 240mm((RAM Height≤30mm))

Rear: 120mm

Cooling System - Installationsanleitung - Guia de instalação - Инструкция по установке - 散热支持

120/140/240/280/360mm

Airflow Direction - Luftstromrichtung - Direção do fluxo de ar - Направление воздушного потока - 气流方向

Pay attention to the airflow direction inside the

chassis.

Achten Sie auf die Luftstromrichtung innerhalb

des Chassis.

Preste atenção à direção do fluxo de ar dentro do

chassi.

Обратите внимание на направление

воздушного потока внутри шасси.

注意机箱内容的气流方向。
