1. Aura Sync ARGB header link to motherboard addressable ARGB port on the motherboard.

2. How to extend fans? 5V3pin ARGB header link additional 3pin male of fan and female fan link to motherboard addressable ARGB port

on the motherboard, (under extension mode, it is available for Aura SYNC only, ie, RGB light mode via software controlled, and build-in

manual mode disable).

3. Click the LED button to switch modes; press and hold for 3 seconds to switch the motherboard synchronization mode, or restore the

self-control mode; press and hold for 5 seconds to turn off the light.

ARGB FAN CONNECTION INSTRUCTION

Link LED SW or RESET SW

Fan Model: FN12A-M6Fan Model: FN12A-S6

Fan Connection Demo - Lüfteranschluss Demo - Demonstração da conexão do ventilador - Демонстрация подключения

вентилятора - 风扇连接演示
