Product overview

Main unit

Laser head pressure sensor

Laser sensor

Infrared docking sensor

Function buttons

Universal wheel

Bumper

Infrared docking sensor/Wall detection

sensor

TOF wall tracking sensor

Panel

Dust box release button

Dust inlet

Mop holder release button

Charging contact (x2)

Infrared sensor

Spot button

• Sho rt pres s to cl ean a loca liz ed ar ea. The robot

automatically docks after cleaning.

• Short press while operating to pause

Reset button

• Short press to automatically restart

Power button

• Short press to start a cleaning cycle. The robot automatically

docks after cleaning.

• Press and hold to turn the robot on or off

• Short press while operating to pause

Dock button

• Short press to dock

Edge sensor (x4)

Charging plates

Side brush (x2)

Driving wheel (x2)

Main brush

Main brush housing release button

Mop

Electric water tank and mopping module

Dust inlet

Filter release button

Dust box + water tank (2 in 1) release button

Dust box + water tank (2 in 1)

Filter

Dust box + water tank (2 in 1)

cover
