16 Français
Warranty
The warranty conditions issued by our relevant sales
company apply in all countries. We shall remedy possi-
ble malfunctions on your appliance within the warranty
period free of cost, provided that a material or manufac-
turing defect is the cause. In a warranty case, please
contact your dealer (with the purchase receipt) or the
next authorised customer service site.
(See overleaf for the address)
Technical data
Exception according to Regulation (EU) 2019/1781 An-
nex I Section 2 (12): j)
Subject to technical changes without notice.
EU Declaration of Conformity
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements in the EU Directives, both in its basic design
and construction as well as in the version placed in cir-
culation by us. This declaration is invalidated by any
changes made to the machine that are not approved by
us.
Product: High-pressure cleaner
Type: 1.324-xxx
Currently applicable EU Directives
2006/42/EC (+2009/127/EC)
2014/30/EU
2011/65/EU
2000/14/EC
2009/125/EC
Commission Regulation(s)
(EU) 2019/1781
Harmonised standards used
EN 60335-1
EN 60335-2-79
EN 62233: 2008
EN 55014-1: 2017 + A11: 2020
EN 55014-2: 2015
EN 61000-3-2: 2014
EN 61000-3-3: 2013
EN IEC 63000: 2018
Applied conformity evaluation method
2000/14/EG: Annex V
Sound power level dB(A)
Measured: 84
Guaranteed: 86
The signatories act on behalf of and with the authority of
the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Ph.: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2022/09/01
Contenu
K 5 WCM WCM
Premium
Electrical connection
Voltage V 230 230
Phase ~ 1 1
Frequency Hz 50 50
Power rating kW 2,1 2,1
Degree of protection IPX5 IPX5
Protection class I I
Power protection (slow-
blowing)
A10 10
Water connection
Feed pressure (max.) MPa 1,2 1,2
Input temperature (max.) °C 40 40
Input amount (min.) l/min 10 10
Suction height (max.) m 0,5 0,5
Device performance data
Operating pressure MPa 12,5 12,5
Max. permissible pressure MPa 14,5 14,5
Water flow rate l/min 7,5 7,5
Maximum flow rate l/min 8,3 8,3
Detergent flow rate l/min 0,3 0,3
High-pressure gun recoil
force
N20 20
Dimensions and weights
Typical operating weight kg 13,9 14,4
Length mm 329 389
Width mm 369 369
Height mm 901 901
Determined values in acc. with EN 60335-2-79
Hand-arm vibration value m/s
2
2,1 2,1
Uncertainty K m/s
2
0,7 0,7
Sound pressure level L
pA
dB(A) 70 70
Uncertainty K
pA
dB(A) 3 3
Sound power level L
WA
+
K uncertainty
WA
dB(A) 86 86
Remarques générales......................................... 17
Protection de l'environnement............................. 17
Utilisation conforme............................................. 17
Accessoires et pièces de rechange .................... 17
Etendue de livraison............................................ 17
Description de l'appareil...................................... 17
Dispositifs de sécurité ......................................... 17
Symboles sur l’appareil....................................... 18
Montage .............................................................. 18
Mise en service ................................................... 18
Fonctionnement .................................................. 19
Transport............................................................. 19
Stockage ............................................................. 19
Entretien et maintenance .................................... 20
Dépannage en cas de pannes ............................ 20
Garantie .............................................................. 21
Caractéristiques techniques................................ 21
Déclaration de conformité UE ............................. 21
