Zalman’s CNPS2005-Plus / 3000-Plus / 3100-Plus / 3100-GP coolers include a new fan
assembly (FB123) with an adjustable bracket and a bigger fan for increased cooling
performance. The new fan assembly can be positioned to provide optimal cooling
in almost any motherboard/case configuration and allows an additional fan to be
installed for cooling a NP VGA Card.
1. Features :
1) Zalman’s CPU Coolers do not generate noise and vibration in Silent Mode.
2) The heat dissipating material of the Flower HeatSink (FHS) is 100% Aluminum or Copper.
3) Separation of the FHS from the CPU fan prevents transfer of the fan's vibration to the CPU.
4) By utilizing a 92mm fan, both the CPU and the motherboard chipset are cooled.
5) The cooling fan can be mounted at any desired location, making it compatible with virtually al l
computer cases and motherboards (Note: computer cases that have the power supply covering the
CPU cannot be used).
6) CPU can be cooled to a temperature sufficiently below the temperature required by the CPU
manufacturer in Silent Mode.
7) Zalman’s CPU Coolers enable very stable operation of a CPU in an OVERCLOCKED environment.
* If you try OVERCLOCKING, please make sure that the fan is in Normal Mode.
* Zalman Tech. Co., Ltd. is not responsible for any damage to systems or CPUs caused by CPU
OVERCLOCKING.
2. Components :
1) FHS (Flower HeatSink) : ZM6548BC-XXXX 2) NP FAN & Bracket : FB123
3) Thermal Grease 4) Screw bolts (Inch-sized/mm-sized bolts)
5) Clip 6) One Noiseless Connector RC56
7) Heatsink Installation Tool (Clip Mate)
3. Specifications :
1) FHS
- 1 -
The specifications of the cooler may change without prior notice to improve the performance thereof.
CNPS2005-Plus, CNPS3000-Plus,
CNPS3100-Plus, CNPS3100-GP
(Gold Plus)
CNPS2005-Plus
ZM6548BC-Al
CNPS3000-Plus
ZM6548BC-AlCu
95~110(L) × 52(W) × 65(H)
2000~2100
CNPS3100-Plus
ZM6548BC-Cu
CNPS3100-GP
(Gold Plus)
ZM6548BC-Gold
Model
Spec.
Part No.
Dimensions (mm)
Dissipating Area (
㎠㎠
)
Base Material
Weight (g)
Thermal
Resistance
(℃/W)
Silent
Mode
Normal
Mode
Pure Aluminum
Pure Aluminum
+ Pure Copper
Pure Copper
with Gold Plating
Pure Copper
119
148
296 296
0.41
0.39
0.34
0.34
0.34
0.32
0.26 0.26
