24
EN
Product
Name NAVEE Electric Scooter
Model NKT2211-A25
Dimensions
Vehicle: L × W × H (mm)
[1]
1140 × 485 × 1165
After Folding: L × W × H (mm) 1140 × 160 × 505
Net Weight Vehicle Net Weight (kg) 16.6
Rider
Load Range (kg) 25–120
Age (years) 16–50
Body Length (cm) 120–200
Assembled
Electric Scooter
Max. Speed (km/h) 25
General Range (km)
[2]
Approx. 50
Max. Climbing Angle (%)
Approx. 20
Suitable Surfaces
Cement or asphalt road, with benches of less than 1 cm or crevices
narrower than 3 cm
Operating Temperature (°C) -10 to 40
Storage Temperature (°C) -20 to 45
IP Rating IP55
Charging Time (h) Approx. 6.5
Battery Pack
Model T2211-BA4A
Nominal Voltage (VDC) 36
Max. Charge Voltage (VDC) 42
Rated Energy (Wh) 367.2
Intelligent Battery
Management System
Over-heating, short circuit, over-current, over-discharge, and
over-charge protection
Normal Charging Temperature
Range (°C)
0 to 40
Rated Capacity (Ah) 10.2
Wheel Motor Rated Power (kW; W) 0.35; 350
Battery Charger
Model
[3]
BCTA+71420-1701
Output Power (kW; W) 0.0697; 69.7
Input Voltage (VAC) 100–240
Max. Output Voltage (VDC) 42
Rated Output (VDC; A) 41; 1.7
Tire Front & Back Tires 10-inch pneumatic tires
Bluetooth
Frequency Band (s) 2.4000 – 2.4835 GHz
Max. RF Power (dBm) 8
[1] Vehicle height: From the ground to the top of the scooter.
[2] General range: Measured when there is no wind and at 77 ° F (25 ° C), the scooter is fully charged to ride at a constant speed of 9.3 mph
(15 km/h) on a flat surface with a load of 165.3 lbs (75 kg)
[3] To recharge the battery, only use the battery charger provided in the package. Please see battery charger parameters in Specifications.
11. Specifications
