3
G Operating instruction
Thank you for choosing aHama product.
Take your time and read the following instructions and information completely.Please keep
these instructions in asafeplace for futurereference. If you sellthe device, please pass
these operating instructions on to the new owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to specic
hazards and risks.
Note
This symbol is used to indicate additional information or important notes.
2. Package Contents
• TV wallbracket
• TV support arms (2x)
Note
Please check that the installation kitiscomplete beforeinstalling the
bracket and ensurethat none of the parts arefaultyordamaged.
3. Safety Notes
Warning
• Given the multitude of terminal devices and wallstructures available on the market,
the supplied mounting kit is unable to cover every option.
• It occasionally happens that the screws for attaching theterminal device to thewall
bracket aretoo long.
• Please note that the supplied wallplugs arefor use with concrete brick and solid
brick walls only.
• Read the operating instructions for your terminal device beforeattempting to mount
it. The instructions provide information about thetype and measurements of suitable
fastening materials.
• If the supplied mounting kit does not contain suitable fasteningmaterialsfor
mounting the terminal device, purchase these from aspecialised dealer.
• If the wallonwhich the bracket is to be mounted is made of different material types
and construction types to those specied, purchase suitable mounting materials from
aspecialised dealer.
•
Never apply force during mounting. This can damage yourend deviceorwallbracket.
• Ifindoubt, have this product mounted by aqualied technician -donot attempt to
mount it yourself!
Note –Commercial use
• If the device is used commercially,increased duty of carerequirements apply.
• Therefore, please observe the accident prevention regulations of the German
employer’sliability insurance association for electrical systemsand equipment.
Please also observe allaccident prevention regulations from other applicable
employer’sliability insurance associations and accident insurance companies, as
wellasany legal regulations applicable to the particular industry and/or location.
• The wallbracket must be installed by trained personnel or by aspecial technician,
especially when installed in schools, educational institutions, hobby/self-service
workshops or other publicly accessibleinstitutions.
• Securethe product and the attached load againstfallingusing suitable equipment
(e.g. an arresting cable) and in accordance with locally applicable regulations. We
strongly recommend these additional safeguards even if they arenot legally required.
• Have trained personnel carry out regular inspectionstoensurethat the product is
securely installed, properly functioning andinacceptable condition (werecommend
inspections at least every 6months, or morefrequently if required for the particular
location) and then document these inspections.
• Do not mount the product above locations wherepersons might linger.
• Once you have mounted the product and the attached load, check that they are
suciently secureand safe to use.
• Youshould repeat this check at regular intervals(at least every three months).
• When doing so, ensurethat the product does not exceed its maximum permitted
carrying capacity and that no load exceeding the maximumpermitted dimensions is
attached.
• Make surethat the product is loaded symmetrically.
• During adjustment, ensurethat the product is loaded symmetrically and that the
maximum permitted carrying capacity is not exceeded.
• Maintain the necessary safety clearance around the attached load (dependingonthe
model).
• Inthe event of damage to the product, remove the attached load and stop using the
product.
4. Intended use and specifications
• The bracket is only intended foruse within buildings.
• Use the bracket only for the intended purpose.
Maximum load bearing
capacity:
R1118172: 40 kg
R1118171: 40 kg
Screen size:
R1118172:
81.0 -165.0 cm (US: 32" -65")
R1118171:
94.0 -203.0 cm (US: 37" -80")
Depth:
R1118172: 7.7 –54.8cm
R1118171: 7.7 –54.8cm
Angle: –10°/+ 5°
Pivoting range:
up to 180° on 3joints (depends on the device)
Wall mounting plate
dimensions:
R1118172: 48.5 x24.6cm
R1118171: 48.5 x24.6cm
Mounting holes:
according to the VESA standarduntil
R1118172: 300x200 -400x400
R1118171: 300x200 -600x400
5. Installation requirementsand installation
Note
• Only mount the TV wallbracket with the help of asecond person. Get the support
and help you need.
• Different end devices havedifferent options forconnecting cables and other devices.
Beforeinstallation, ensurethat the necessary connections willstillbeaccessible
after installation.
• The same mounting kit is included with allofour TV wallbrackets. Depending on
the product and mounting type, youmay not need to use the entiremounting kit.
Unneeded screws and other smallparts may be left over,even if the wallbracket
is properly mounted. Keep these leftover parts with the operating instructions in a
safe place, just in case youmight need them later on (e.g. should you move, sellthe
product, mount the wallbracket in adifferent location, buyanew TV,etc).
Warning
• This product is suitable for wallmounting only.
• Beforeinstalling the bracket, ensurethat the wallonwhich the television is to be
mounted is suitable for the weight and make sure that no electrical wires, water,gas
or other lines arelocated at the installation location.
• Please note that the provided wallanchors areonly approved forconcrete and solid
brick walls.
• Observe the other warnings and safety instructions.
• Proceed step-for-step in accordance with the illustrated installation instructions (Fig. 1ff.).
• The shackle diameter of the padlock shouldbe4to8mm. (Padlock not included in the
delivery package)
Note
• Given the multitude of terminal devices available on the market, we cannot describe
allpossible mounting options here.
• Please ensurethat the bracket lays at and evenly on the back of the television.
• Use the enclosed spacer to even out any unevenness on the back of the television.
• Ensurethat allscrews have the proper length and can be mounted until they are
hand-tight (see Fig. 3).
6. Setting and maintenance
Note
Only adjust the TV wallbracket with the help of asecond person. Get the support and
help you need.
• To adjust the inclination, loosen the side mounting screws slightly,set the desired angle
and retighten the screws securely.
• Slide the metal rodbetween the wallplate and the carrying arms into the appropriate
guiding slots to securethe bracket.
• The bracket can only be unlocked and the TV removed if no padlock is attached.
• Check that the bracket is secureand safe to use at regular intervals (at least every three
months). Only use water or standardhouseholdcleaners for cleaning.
7. Warranty Disclaimer
Hama GmbH &CoKGassumes no liability and provides no warranty for damage resulting
from improper installation/mounting, improper use of the product or from failuretoobserve
the operating instructions and/orsafety notes.
• Installation kit (see contents, Fig. 1)
• These operating instructions
