Cleaning and Replacing Parts

Attention:

1.HEPA lter is available for sale from local

vacuum cleaner distributors.

2.It is recommended to clean the dust cup after

each use; When the dust cup is full or the

HEPA lter is clogged, it needs to be cleaned

and replaced if necessary.

3.Electric oor head brushroll might be entangled

with hair after long time use. It needs to be

cleaned in time to keep the vacuum working

more efciently.

Clean dust cup and ltration system

When dust cup is full or HEPA is clogged, LED

screen will display HEPA icon as the picture to

remind to clean dust cup and lter. Please clean

dust cup and HEPA ler in time. Replace HEPA

lter if necessary.(Fig 11)

Steps of cleaning dust cup and ltration

system:

1.Press dust cup bottom cover release button,

open dust cup bottom cover, dump dust into

trash can.(Fig 12)

2.Lift up HEPA lid assembly from dust cup.

Rotate HEPA lter clockwise and remove it

from HEPA lid for washing. After washing, HEPA

need to be completely dry before using it again.

(Fig 13)(Fig 14)

3.Push dust cup release button located behind

the dust cup and remove dust cup. Hold cyclone

assembly handle and pull it out of dust cup.

Disassemble cyclone top, secondary dust cup,

adjustment ring and inner cyclone in sequence

for cleaning. After washing, all parts need to be

completely dry before using again. After cleaning,

assemble the parts back in the opposite

sequence of disassembly.(Fig 15)(Fig16)

Dust cup release

button
