Air path cleaning

Disassemble the dirty water tank, take out dirty water tank

upper cover and garbage basket, wash all parts and them

asssemble back. Use cleaning brush to clean the dirt,

foreign objects and hair inside air path of oorhead. Put

dirt water tank back into mainbody.

Remove the dust cup,then take out cyclone , empty the

dust cup, remove HEPA, clean all parts and reassemble

the dust cup. (Refer to "Cleaning and Maintenance" for

details)

Voice reminding function

The product includes voice reminding of 5 different

language: English, German, Italian, French and Russian.

Voice of the new machine is turned on and in English

by default, press the voice button to switch to other

language, keep pressing the voice button to turn off the

voice function; press the voice button again to turn on the

voice function. (Fig 16)

Note: When the product is used as handheld vacuum

cleaner or stick vacuum cleaner, there is no voice

function.

Battery low power indicator

1.When the stick cleaner is working, if the voice reminds

"Low battery. Please charge the battery", Please use it

after charging.

2.When the stick cleaner is working, if the voice reminds "Low battery. Machine will be turned off soon. Please

charge the battery", the power is about to be exhausted, and it will automatically shut down. Need to charge

for use.

3. When using vacuum cleaner, the icon on LED sceen displays left working minutes. When battery power is

lower than 20%, the battery icon on right top corner turns from white to red.

Chapter 3 Cleaning and Maintenance

Dirty water tank cleaning

After turning off the vacuum cleaner, remove the dirty water tank, lift the water tank top cover, and remove

the lter frame from it, open the ip cover of the lter frame, take out the lter. Pour out dirty water and dirt in

the water tank, then wash dirty water tank, water tank cover, lter frame and lter. If there is foreign matter

in the dirty water tank pipe, it can be cleaned with cleaning brush; dry the above parts after washing. And

then reassemble all the parts back into dirty water tank. Put dirty water tank back into mainbody to continue

working. (Fig 17)

Note:

1. After using stick vacuum cleaner, it is recommended to clean the dirty tank immediately;

2. When reinstalling the garbage basket,do not fold the black soft rubber under the lter.

Floorhead cleaning

After removing the clean water tank, brushroll, and dirty water tank, insert the cleaning brush through the circular

hole below the installation position of the mainbody to clear foreign matter and scales in the pipe, and the clogged

hair; Use the blade on the mini brush to cut off the entangled hair on the brushroll; Wipe the dirty parts of the

Voice

button

Dirty water tank

cleaning
