Xiaomi S28D Sound Pocket 5W Руководство по эксплуатации онлайн

English

Instructions

Basic Features

1) Power on/oﬀ

Long press the power buon for 2 seconds to turn on the speaker and begin Bluetooth

pairing, or to turn the speaker oﬀ. This process includes voice prompts.

2) Bluetooth connection

When the speaker is in the Bluetooth pairing mode, turn on your mobile phone’s Bluetooth

functions, then select “Xiaomi Sound Pocket” from the Bluetooth pairing list and click to pair.

You will hear a prompt when pairing is successful.

To disconnect the speaker, short press buon and the speaker will switch to Bluetooth

pairing mode.

Other Features

Long press the and buon 5s to clear the pairing list and restore the default volume.

Indicator light fast blinking

Indicator light on

Indicator light fast blinking

Indicator light slowly blinking

Indicator light on

The speaker is in the Bluetooth pairing mode.

The speaker is paired with a device, such as a smartphone.

Two speakers are searching for each other for TWS.

The speaker is charging

The speaker ﬁnish charging

5) Indicator Light

Two speakers pair successfully but are not connected to a

smartphone or other devices.

Basic Speciﬁcations

Product model no.: MDZ-37-DB

Bluetooth version: 5.4

Supports: A2DP V1.4, AVRCP V1.6.2, HFP V1.8

Speaker unit: 1

Rated output power: 5W (@1KHz THD=1%)

Frequency range: 100Hz to 20KHz

Signal-to-noise ratio: ≥70dB

Bluetooth transmier power: 2 to 6 dBm

Bluetooth transmier frequency range:

2.400–2.4835GHz

Bluetooth transmier modulation:

GFSK,π/4-DQPSK,8-DPSK

4) Calls

If a call comes in when the speaker is connected with a smartphone, the speaker will

automatically pause the music and play a ringtone. When this happens, short press buon

to answer; short press buon again to end the call. Long press buon for 2 seconds to

reject the call.

long press ” “ more than 1s to switch between mobile and speaker.

Indicator light oﬀ

Short press: volume down Play/Pause

Answer/End call

Press 3 times: previous track

Press 2 times: next track

Short press: volume up

3) Stereo pair

Long press buon 3s on a speaker, another speaker is under bluetooth pairing status, two

speakers will pair automatically and operate as le and right channels respectively.

(If connection fails, short press buon on another speaker.)

To disconnect, long press buon for 3 seconds on either of the speaker.

Baery: Lithium-ion, 3.7V, 1000mAh

Baery charging: 5V 1A, 3hours

Play duration: approx. 10hours (at 40% volume)

Pocket

Sound

• instruction manuals. Do not connect

incompatible devices to this device.

• For AC/DC adapters, the socket-outlet shall

be installed near the equipment and shall be

easily accessible.

CAUTION

• RISK OF EXPLOSION IF BATTERY IS

REPLACED BY AN INCORRECT TYPE.

• DISPOSE OF USED BATTERIES ACCORDING

TO INSTRUCTIONS.

THIS LEGAL WARRANTY NOTICE INFORMS

YOU ABOUT YOUR RIGHTS UNDER THE LEGAL

WARRANTY. FOR A FULL UNDERSTANDING OF

YOUR RIGHTS YOU ARE INVITED TO CONSULT

THE LAWS OF YOUR COUNTRY, PROVINCE OR

STATE.

The duration and conditions related to the legal

warranties are provided by respective local

laws. For more information about the

consumer warranty benefits, please refer to

Xiaomi's official website

https://www.mi.com/global/support/warranty.

If you have purchased the Product directly

from Xiaomi. In all other cases, please consult

your seller. There is no guarantee that the

operation of the Product will be uninterrupted

or error free. Damages arising from

non-compliance with the instructions related

to the use of the Product are excluded. If a

hardware defect is found within the Warranty

period, the Product will be either (1) repaired,

(2) replaced, or (3) refunded, depending on your

rights under local laws. Normal wear and tear,

force majeure, abuse or damage caused by the

user's negligence or fault are not warranted.

The contact person for the after-sales service

may be any person in Xiaomi's authorized

service network, Xiaomi's authorized

distributors or the final vendor who sold the

Products to you.

The present warranty does not apply in Hong

Kong and Taiwan.

Products which were not duly imported and/or

were not duly manufactured by Xiaomi and/or

were not duly acquired from Xiaomi or a

Xiaomi’s official seller are not covered by the

present warranties. As per applicable law you

may benefit from warranties from the

non-official retailer who sold the Product.

Therefore, Xiaomi invites you to contact the

retailer from whom you purchased the Product.

WARRANTY NOTICE

Important Safety Information

Read all safety information below before using

your device:

• Use of unauthorized cables, power adapters,

or batteries can cause fire, explosion, or pose

other risks.

• Use only authorized accessories which are

compatible with your device.

• This device’s operating temperature range is

0°C to 40°C. Using this device in an

environment outside of this temperature

range may damage the device.

• If your device is provided with a built-in

battery, to avoid damaging the battery or the

device, do not attempt to replace the battery

yourself.

• Charge this device only with the included or

authorized cable and power adapter. Using

other adapters may cause fire, electric shock,

and damage the device and the adapter.

• After charging is complete, disconnect the

adapter from both the device and the power

outlet. Do not charge the device for more

than 12 hours.

• The battery must be recycled or disposed of

separately from household waste.

Mishandling the battery may cause fire or

explosion. Dispose of or recycle the device, its

battery, and accessories according to your

local regulations.

• Do not disassemble, hit, crush, or burn the

battery. If the battery appears deformed or

damaged, stop using it immediately.

• Do not short circuit the battery, as this may

cause overheating, burns, or other injury.

• Do not place the battery in a

high-temperature environment.

• Overheating may cause explosion.

• Do not disassemble, hit, or crush the battery,

as this may cause the battery to leak,

overheat, or explode.

• Do not burn the battery, as this may cause fire

or explosion.

• If the battery appears deformed or damaged,

stop using it immediately.

• User shall not remove or alter the battery.

Removal or repair of the battery shall only be

done by an authorized repair center of the

manufacturer.

• Keep your device dry.

• Do not try to repair the device yourself. If any

part of the device does not work properly,

contact Xiaomi customer support or bring

your device to an authorized repair center.

• Connect other devices according to their

RoHS compliance – European Union

Xiaomi products sold in the European Union,

meet the requirements of Directive 2011/65/EU

and its subsequent amendments directive (EU)

2015/863 on the restriction of the use of certain

hazardous substances in electrical and

electronic equipment

Simpliﬁed EU Declaration of Conformity

Hereby, Beĳing Xiaomi Electronics Co.,Ltd

declares that the radio equipment type Xiaomi

Sound Pocket is in compliance with Directive

2014/53/EU.

The full text of the EU declaration of conformity

is available at the following internet address:

http://www.mi.com/global/service/support/dec

laration.html

RF Frequency and Power

This device oﬀers the following frequency

bands in EU areas only and maximum

radio-frequency power

Bluetooth: 20 dBm

For the purpose of recycling to facilitate

effective utilization of resources, please return

this product to a nearby authorized Collection

Centre, registered Dismantler or Recycler when

disposing of this product.

What the Wheelie Bin symbol means: The

symbol says don’t dispose your e-waste into

the municipal waste collection bins. That’s

because these wastes are hazardous in nature

and need to be recycled in a special way.

Notes
