10 English

17 Air quality sensor

18 Connection Power supply unit AF 30

19 Connecting cable AF50

20 Steering rollers AF50 (4x)

21 Filter cover

22 filter

23 Power adapter AF30

Note

The function settings are only possible via the operation

buttons and not via the displays.

Initial Start-Up

Before initial start up, the fine filters already installed in

the unit must be unpacked.

1. Open the two filter covers on the recessed grip and

remove them with both hands.

Illustration B

Illustration C

2. Remove the packed filters from the casing using the

tabs.

Illustration D

3. Unpack the filters.

Illustration E

4. Insert the unpacked filters.

Illustration F

5. Insert the filter cover firmly with both hands.

Illustration G

6. Place the device on a level surface. Ensure that a

distance of 0.30 m is maintained to each side.

Illustration H

7. Make sure that the air intake and air outlet openings

are not blocked.

Note

Do not place the device on hot surfaces or in the imme-

diate vicinity of the room heating.

Do not allow any liquids or foreign bodies (e.g. metallic

objects) to enter the device.

8. AF 30: Insert the unit plug of the power supply unit

into the device.

Plug the mains plug of the power supply unit into a

socket.

AF 50: Plug the mains plug of the device into a

mains socket.

Illustration I

The device is ready for operation.

Note

The first time you use the device, we recommend allow-

ing it to run overnight to perform an initial basic cleaning

of your room.

Note

The table with the hours of the display symbols for the

filter service life, see Replacing the filter

Operation

Switching the device on/off

1. To switch on the device: Press the on/off button on

the device.

Illustration I

The device starts automatically.

Note

After the system is switched on, the displays and but-

tons on the control panel light up briefly. The integrated

air quality sensor measures the air quality in the room

automatically.

2. If required, the following functions, for example, can

be set via the operation buttons:

 Fan level

 Auto mode

 ECO mode

 Sleep mode

 Lock control panel

 Timer

 Filter reset

3. To switch off the device: Press the On/Off switch of

the device.

The displays and buttons on the control panel go

out. The device is switched off.

Setting the fan level

Depending on the air quality, the fan level can be man-

ually set to level 1, 2, 3, 4 or 5. If the air quality is poor,

for example to filter out smoke, the blower should run at

maximum speed (level 5) for 15 - 20 minutes.

Note

To clean the air effectively, keep windows and doors

closed while the air purifier is switched on.

Symbol Operation button for the fan level:

● Press the fan level operation button repeatedly until

the desired level is reached.

The selected fan level is displayed on the control

panel.

Note

When selecting the fan level manually, the selected

speed is shown on the display for 3 seconds before the

PM 2.5 index values are shown again on the display.

Setting auto mode

In auto mode, the air purifier sets the appropriate fan

level (level 1, 2, 3, 4, 5) depending on the air quality.

In the event of poor air quality, for example, the fan level

is automatically set high.

Symbol Operation button and indicator for auto mode:

 Press the Auto mode operation button. The auto-

matic mode is switched on or off.

Setting ECO / power saving function

Switch power saving mode on / off

Symbol Operation button and indicator for ECO / power

saving mode

The device is in working mode:

● Press the ECO mode operation button.

The device switches to power saving mode and

the display is

switched off.
