Руководство по эксплуатации Страница: 12

Bort TRAVEL Руководство по эксплуатации онлайн [12/24] 879970

PRODUCT PARAMETERS

Voltage 220-240 V

Rated frequency 50-60 Hz

Rated power 1300 W

Operating temperature 150°C

Heating time 10 s

Continuous operation time 5-7 min

Auto-off function -

Steam power adjustment -

Low water level indicator +

Automatic shutdown -

Overheating protection +

Volume of the water tank 80 ml (MAX)

Weight 800 g

Power cord length 1,75 m

IP IPX4

INSTRUCTIONS FOR USE

WATER INJECTION METHOD (FIGURE 2)

1. Remove the water tank from the main machine, as shown in Figure A.

2. Open the water tank cover; fill the tank with water at the water inlet with a measuring cup; after filling with

water, close the water tank cover and wipe the surface dry. It is not recommended to turn on the tap to

directly fill the tank with water, as shown in Figure B.

HOW TO USE THE STEAM IRONING FUNCTION

1. Plug the power cord into a socket connected to the rated voltage. The indicator light is always on. Place

the steam iron on the accessory base for heating. When the indicator light goes out, it indicates that the

temperature has reached a stable level and you can start ironing clothes. When using intermittently, turn off

the steam switch before placing the product on the base.

2. After use, please turn off the steam switch first, and then pull out the plug to keep the product under power-

off condition. Pour out the water left in the water tank. Store it properly after the electric iron is completely

cooled.

Note: In order to prevent the clothes and ironing soleplate from being damaged, please do not leave the

heating soleplate in the same position for more than 30 seconds. When not in use, please turn off the steam

switch first and then put the iron head on the base.

HOW TO USE THE STEAM IRONING FUNCTION (FIGURE 3)

• Rotate the ironing soleplate 90° as shown in the figure (counterclockwise). Then plug the power cord into

a socket connected to the rated voltage. When the temperature indicator light goes out, turn on the steam

button switch for ironing. When ironing, straighten the clothes being ironed with one hand, hold the machine

with the other hand, press the steam hole close to the clothes and iron the clothes from top to bottom.

Thick clothes need to be ironed several more times. Place the product on the base during intermittent use.

• After use, please turn off the steam switch first, and then pull out the plug to keep the product under power-

off condition. Pour out the water left in the water tank. Store it properly after the electric iron is completely

cooled.

Note: In order to prevent the clothes and ironing soleplate from being damaged, please do not leave the

heating soleplate in the same position for more than 30 seconds. When not in use, please put the iron head

on the base of the main machine.

HOW TO USE THE DRY IRONING FUNCTION

• Do not add water into the water tank during dry ironing. Plug the power cord into a socket connected to the

rated voltage. The indicator light is always on. Place the electric iron on the accessory base for heating.
