• In order to prolong the service life of the steam washing

machine, it is recommended to use pure water.

INSTALLATION OF FLOOR WASHER

1. Installation of oor washer handle and telescopic

aluminum rod:

The semicircular notch of the aluminum rod mouth is in

the same direction as the semicircular protrusion of the

handle connector. Press the upper and lower buckles of

the handle connector, align the aluminum rod mouth,

and insert the circular buckles of the handle connector

into the upper and lower circular holes of the aluminum

rod. Press the button to pull out the handle during dis-

assembly.

• Semicircular notch (g. 3).

2. Installation of electric rotary oor mop and circular

dual material mop:

Align the two circular mops with the left and right wheels

respectively, and gently press them on the left and right

wheels to rmly adhere (g. 4).

3. Main body and electric rotating ground tractor:

Align the snap hole at the lower end of the fuselage with

the snap direction of the base interface, and insert it

downward into the base interface until it clicks in place;

When disassembling, the base interface is buckled, and

the body can be pulled out.

• Body snap hole (g. 5);

• Base interface buckle (g. 5).

4. Connection / disassembly of telescopic aluminum

rod and main body:

Insert the snap of the telescopic aluminum rod into the

xing hole of the telescopic rod of the fuselage until a

click is heard; Press the telescopic rod removal switch in

the direction of the arrow in the right gure below, and

pull out the telescopic aluminum rod upward to remove

the telescopic aluminum rod.

• Telescopic rod removal switch (g. 6).

5. The product height is adjustable from 1m to 1.2 m:

Pull the telescopic lever switch clockwise and release the

xing block to adjust between 1m and 1.2m at will; When

it is adjusted to the ideal height for personal use, pull the

telescopic lever switch anticlockwise and fasten the xing

block, then it can be used normally.

• Telescopic lever switch (g. 7).

6. Add water to the water tank:

As shown in the gure below, take out the water tank, lift

the water tank cover, ll the measuring cup with water

(the water tank capacity is 550 ml), cover the water tank

cover and install it on the main body.

• Water tank push button (g. 8).

7. Power cord storage:

The winding hook easily stores the power cord.

• Winding hookа (g. 9).

8. Installation and use of steam washer accessories:

Align the snap of the straight nozzle with the snap hole

of the main engine and insert it into the interface of the

main engine (g. 10);

To connect other accessories, proceed in the same way.

OPERATING PANEL INSTRUCTIONS (FIG. 11)

1. Plug on the power supply, press the steam switch, the

product starts to heat, the red light of the heating indi-

cator ashes, and the red light of the heating indicator

is always on after the heating is completed.

2. Steam on / o key: press the steam selection key to se-

lect the rst gear steam once, and the steam indicator

light will be yellow; Press twice to select the second gear

steam, and the steam indicator light will be blue; Press

three times to select the third gear steam, and the steam

indicator lights up green; Close the steam for 4 times

and circulate it in sequence.

3. Motor start / stop switch: press once to start the motor,

then press once to turn o the motor, and cycle in turn.

4. Water shortage protection: when the PCB detects that

the water tank is short of water, the heating indicator

light and the steam indicator light ash 6 times in turn,

and then turn o the power supply of the heater and

the water pump.

5. Press and hold for 3 seconds or press the general switch

key to close the steam function and motor function at

the same time.

ELECTRICAL EXTENSIONS

The use of extension cords is allowed, provided you take

some precautions. Use an extension cord that supports

the current required by the device. The extension cord

must be grounded to ensure electrical safety.

The extension cord must be positioned so that it does

not hang from a countertop or table to avoid accidental-

ly tripping over, snagging or pulling on it (especially by

children).

SERVICE

Have your power tool serviced by a qualied repair person

using only identical replacement parts. This will ensure

that the safety of the power tool is maintained.

DISPOSAL

Discarded electric appliances are recyclable and

should not be discarded in the domestic waste!

Please actively support us in conserving resources

and protecting the environment by returning this

appliance to the collection centres (if available).

Made in China.
