English

ted. Local directives or general directives [e.g. IEC,

VDE etc.] and local power supply companies must

be adhered to.

2.5 Safety instructions for installation and main-

tenance work

The operator must ensure that all installation

and maintenance work is carried out by authori-

sed and qualied personnel who are sufciently

informed from their own detailed study of the

operating instructions.

Work on the product/unit must only be carried out

when at a standstill. It is mandatory that the pro-

cedure described in the installation and operating

instructions for shutting down the product/unit

be complied with.

Immediately on conclusion of the work, all safety

and protective devices must be put back in posi-

tion and/or recommissioned.

2.6 Unauthorised modication and manufacture of

spare parts

Unauthorised modication and manufacture of

spare parts will impair the safety of the product/

personnel and will make void the manufacturer’s

declarations regarding safety.

Modications to the product are only permissible

after consultation with the manufacturer. Original

spare parts and accessories authorised by the

manufacturer ensure safety. The use of other

parts will absolve us of liability for consequential

events.

2.7 Improper use

The operating safety of the supplied product is

only guaranteed for conventional use in accor-

dance with Section 4 of the operating instruc-

tions. The limit values must on no account fall

under or exceed those specied in the catalogue/

data sheet.

3. Transport and interim storage

When receiving the material, check that there

has been no damage during transport. If shipping

damage has occurred, take all necessary steps

with the carrier within the allowed time.

CAUTION! If the delivered material is to be instal-

led later on, store it in a dry place and protect it

from impacts and any outside inuences (humi-

dity, frost etc.).

4. Product and accessories

4.1 Application

Pumps for lifting of domestic waste water contai-

ning particle lower than 30 mm.

• For xed installation in a sump or a tank.

4.2 Description (Fig. 1)

1 : Check valve adapted to the conveyed medium.

2 : Isolating valve.

3 : Overow audible signal.

4 : Pump lifting chain.

5 : Motor cable - length 10 m.

4.3 The pump

• Submersible monobloc electropump.

• Centrifugal single-stage with vortex impeller.

• horizontal or vertical (with bend) discharge port.

• Tightness with lip seal.

4.4 The motor

Monophase: thermal protection with an integra-

ted probe, automatic reset, delivered with electric

cable - length 10 m with a CEI 23-5 plug and oat

switch.

Integrated condenser.

Technical data

4.4 Accessories (optional)

• Isolating valve • Ball check valve • Float switch

• Audible overow signal AlarmControl • Control

box • Lifting chain ...

The use of new accessories is recommended.

Mains voltage 1~230 V, ± 10 %

Mains frequency 50 Hz

Protection class IP68

Insulation class 155

Speed 2 900 rpm (50 Hz)

Max. current consumption See name plate

Power consumption P1 See name plate

Max. ow rate See name plate

Max. delivery head See name plate

Operating mode S1 200 operating hours a year

Operating mode S3

(optimum)

Intermittent duty, 25 %

(2.5 min. operation, 7.5 min.

interval).

Recommended switching

frequency

20/h

Free ball passage Ø20mm

Nominal diameter of

the pressure port

Ø40 mm (R 1“1/2),

threaded bend Rp 1“1/2

Admissible uid temperature +3 to 35 °C

Max. submersion depth 5 m

Flat suction up to 40 mm

Maximum uid density 1060 kg/m3

Installation and operating instructions - Wilo-Initial DRAIN
